DETAILED COOLING CAPACITIES# CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To tal Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
186BNA060****A Outdoor Section With CNPV*6124A**+TDR Indoor Section
1750
57 (13.9) 66.03 33.71 3.54 62.86 32.49 3.92 59.49 31.24 4.33 55.92 29.95 4.78 52.09 28.60 5.29 47.94 27.18 5.86 62 (16.7) 60.16 42.01 3.52 57.34 40.81 3.90 54.33 39.55 4.30 51.12 38.25 4.75 47.67 36.88 5.26 43.93 35.42 5.83
63 (17.2)†† 55.92 40.36 3.52 53.34 39.17 3.88 50.59 37.93 4.28 47.64 36.64 4.73 44.45 35.28 5.23 41.00 33.82 5.81
67 (19.4) 55.30 50.14 3.52 52.96 52.74 3.88 50.72 50.72 4.28 48.29 48.29 4.73 45.62 45.62 5.24 42.65 42.65 5.83 72 (22.2) 54.87 54.87 3.51 52.85 52.85 3.88 50.64 50.64 4.28 48.23 48.23 4.73 45.56 45.56 5.24 42.60 42.60 5.83
2000
57 (13.9) 66.94 35.49 3.63 63.63 34.26 4.01 60.13 32.98 4.43 56.41 31.66 4.88 52.46 30.30 5.39 48.19 28.86 5.96 62 (16.7) 61.07 44.91 3.62 58.11 43.67 3.99 55.00 42.39 4.40 51.67 41.04 4.85 48.13 39.62 5.36 44.32 38.08 5.93
63 (17.2)†† 56.81 43.05 3.61 54.12 41.83 3.98 51.26 40.56 4.38 48.20 39.22 4.83 44.93 37.80 5.34 41.42 36.25 5.91
67 (19.4) 57.02 57.02 3.61 54.82 54.82 3.98 52.43 52.43 4.39 49.82 49.82 4.84 46.96 46.96 5.35 43.79 43.79 5.93 72 (22.2) 56.95 56.95 3.61 54.75 54.75 3.98 52.36 52.36 4.39 49.76 49.76 4.84 46.90 46.90 5.35 43.74 43.74 5.93
2250
57 (13.9) 67.58 37.19 3.73 64.15 35.93 4.11 60.53 34.64 4.53 56.72 33.31 4.98 52.67 31.92 5.49 48.30 30.47 6.06 62 (16.7) 61.73 47.68 3.71 58.69 46.41 4.09 55.48 45.08 4.50 52.08 43.68 4.95 48.50 42.18 5.46 44.73 44.51 6.03
63 (17.2)†† 57.47 45.62 3.71 54.69 44.36 4.08 51.76 43.04 4.48 48.64 41.65 4.93 45.33 40.11 5.43 41.94 41.94 6.01
67 (19.4) 58.71 58.71 3.71 56.35 56.35 4.08 53.80 53.80 4.49 51.03 51.03 4.94 48.01 48.01 5.45 44.66 44.66 6.03 72 (22.2) 58.64 58.64 3.71 56.29 56.29 4.08 53.74 53.74 4.49 50.98 50.98 4.94 47.96 47.96 5.45 44.62 44.62 6.03
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To tal Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
186BNA061****A Outdoor Section With CNPV*6124A**+TDR Indoor Section
1750
72 (22.2) 68.26 35.40 3.65 65.62 34.24 4.19 62.70 33.02 4.80 59.44 31.72 5.50 55.84 30.35 6.31 51.84 28.89 7.25 67 (19.4) 62.16 43.65 3.59 59.80 42.52 4.12 57.18 41.32 4.72 54.27 40.05 5.42 51.03 38.69 6.24 47.43 37.23 7.18
63 (17.2)†† 57.75 41.99 3.55 55.60 40.87 4.07 53.20 39.69 4.67 50.52 38.42 5.37 47.55 37.07 6.18 44.22 35.62 7.13
62 (16.7) 56.92 51.79 3.54 54.89 50.66 4.07 52.67 49.40 4.67 50.45 50.45 5.37 48.08 48.08 6.19 45.35 45.35 7.15 57 (13.9) 55.79 55.79 3.53 54.23 54.23 4.06 52.43 52.43 4.67 50.37 50.37 5.37 48.01 48.01 6.19 45.29 45.29 7.15
2000
72 (22.2) 69.37 37.22 3.75 66.58 36.03 4.29 63.50 34.78 4.91 60.12 33.47 5.61 56.36 32.08 6.43 52.22 30.60 7.37 67 (19.4) 63.22 46.57 3.69 60.75 45.42 4.22 58.00 44.20 4.83 54.96 42.90 5.54 51.60 41.51 6.35 47.88 40.00 7.30
63 (17.2)†† 58.79 44.71 3.64 56.53 43.57 4.17 53.99 42.35 4.78 51.22 41.07 5.48 48.12 39.67 6.30 44.70 38.17 7.25
62 (16.7) 58.30 55.64 3.64 56.40 56.40 4.18 54.43 54.43 4.79 52.18 52.18 5.50 49.62 49.62 6.32 46.69 46.69 7.28 57 (13.9) 58.04 58.04 3.64 56.32 56.32 4.17 54.35 54.35 4.79 52.12 52.12 5.50 49.56 49.56 6.32 46.64 46.64 7.28
2250
72 (22.2) 70.16 38.93 3.85 67.25 37.73 4.39 64.06 36.47 5.01 60.55 35.14 5.72 56.68 33.73 6.54 52.43 32.24 7.48 67 (19.4) 64.02 49.36 3.79 61.43 48.19 4.32 58.58 46.94 4.94 55.46 45.61 5.65 52.01 44.17 6.47 48.25 42.59 7.41
63 (17.2)†† 59.57 47.31 3.74 57.21 46.14 4.28 54.61 44.90 4.89 51.73 43.57 5.59 48.56 42.13 6.41 45.09 40.51 7.36
62 (16.7) 59.97 59.97 3.75 58.12 58.12 4.29 55.99 55.99 4.91 53.58 53.58 5.62 50.85 50.85 6.45 47.74 47.74 7.41 57 (13.9) 59.89 59.89 3.75 58.04 58.04 4.29 55.93 55.93 4.91 53.52 53.52 5.62 50.79 50.79 6.45 47.69 47.69 7.40
* Tested combination. { Total and sensible capacities are net capacities. Blower motor heat has been subtracted. } Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil a ir f or ea ch degree below 80_F(27_C), or add 835 Btuh (245 kW)
per 1000 CFM (480 L/S) of indoor coil ai r per degree above 80_F(27_C).
# Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per AHRI standard 210/240--- 2008. If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity may occur . ** System kw is total of indoor and outdoor unit kilowatts. {{ At TVA rating indoor condition (75_F edb/63_F ewb). All other indoor air temperatures are at 80_F edb. NOTE: When the required da ta falls between the published data, interpolati on may be perfo rmed. Extrapolation is not an acceptable practice. EWB — Entering Wet Bulb
