Bryant PREFERRED 265A - Page 30

30
HEAT PUMP HEATING PERFORMANCE CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
-- 3 7 17 27 37 47 57 67
EDB CFM
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ*
265ANA048-- B Outdoo r Section With FX4CNF 060 Indoor Section
65
1400 19.54 17.98 2.79 24.30 22.33 2.91 29.42 26.83 3.02 34.92 31.02 3.15 41.16 37.45 3.30 48.11 48.11 3.47 56.36 56.36 3.64 64.59 64.59 3.87 1600 19.84 18.25 2.80 24.62 22.63 2.90 29.78 27.15 3.01 35.34 31.38 3.12 41.92 38.14 3.25 48.81 48.81 3.40 56.71 56.71 3.53 64.00 64.00 3.70 1800 20.10 18.49 2.82 24.91 22.89 2.91 30.09 27.44 3.00 35.69 31.70 3.10 42.11 38.32 3.22 49.41 49.41 3.33 56.74 56.74 3.46 61.21 61.21 3.54
70
1400 18.95 17.44 2.92 23.74 21.82 3.05 28.89 26.34 3.17 34.39 30.55 3.31 40.39 36.75 3.46 47.33 47.33 3.65 55.45 55.45 3.84 63.71 63.71 4.07 1600 19.25 17.71 2.93 24.07 22.12 3.04 29.26 26.68 3.15 34.81 30.92 3.28 40.92 37.23 3.41 48.00 48.00 3.58 56.03 56.03 3.72 63.79 63.79 3.91 1800 19.52 17.96 2.95 24.36 22.39 3.05 29.58 26.97 3.15 35.16 31.23 3.26 41.37 37.65 3.38 48.57 48.57 3.52 56.18 56.18 3.65 62.11 62.11 3.77
75
1400 18.32 16.86 3.05 23.16 21.28 3.19 28.33 25.83 3.33 33.84 30.06 3.48 39.77 36.19 3.64 46.58 46.58 3.84 54.50 54.50 4.05 62.93 62.93 4.28 1600 18.63 17.14 3.06 23.49 21.59 3.18 28.71 26.17 3.31 34.27 30.43 3.44 40.26 36.64 3.58 47.22 47.22 3.76 55.33 55.33 3.91 63.06 63.06 4.12 1800 18.89 17.38 3.08 23.79 21.86 3.19 29.03 26.46 3.30 34.63 30.75 3.42 40.70 37.04 3.55 47.76 47.76 3.71 55.56 55.56 3.84 62.40 62.40 4.00
Heating Indoor Model Capacity Power Furnace Model
*FX4CN(B,F)060 1.00 1.00
FE4ANB006 0.98 1.00
FE4ANF005 0.98 1.04
FV4BNB006 0.98 1.00
FV4BNF005 0.98 1.04
FX4CN(B,F)048 1.00 1.04
FY4ANB060 1.02 1.08
FY4ANF048 1.00 1.09
CAP**4817A** 0.99 1.08 CAP**4821A** 1.01 1.09 CAP**4824A** 1.01 1.09 CAP**6021A** 1.01 1.08 CAP**6024A** 1.01 1.08
CNPF*4818A** 0.98 1.11
CNPH*4821A** 1.01 1.09 CNPH*6024A** 1.01 1.08 CNPV*4821A** 1.01 1.09 CNPV*4824A** 1.01 1.09 CNPV*6024A** 1.01 1.08 CSPH*4812A** 1.01 1.08 CSPH*6012A** 1.01 1.06
CAP**4817A** 0.98 1.07 315(A,J)AV048090
CNPH*4821A** 0.98 1.08 315(A,J)AV048090 CNPH*6024A** 0.98 1.06 315(A,J)AV048090 CSPH*4812A** 0.98 1.07 315(A,J)AV048090 CSPH*6012A** 0.98 1.05 315(A,J)AV048090
CAP**4821A** 0.98 1.07 315(A,J)AV060110 CAP**6021A** 0.98 1.05 315(A,J)AV060110
CNPH*4821A** 0.98 1.07 315(A,J)AV060110 CNPH*6024A** 0.98 1.05 315(A,J)AV060110 CNPV*4821A** 0.98 1.07 315(A,J)AV060110 CSPH*4812A** 0.98 1.06 315(A,J)AV060110 CSPH*6012A** 0.98 1.04 315(A,J)AV060110
CAP**4824A** 0.98 1.06 315(A,J)AV066135 CAP**6024A** 0.98 1.04 315(A,J)AV066135
CNPH*4821A** 0.98 1.06 315(A,J)AV066135 CNPH*6024A** 0.98 1.05 315(A,J)AV066135 CNPV*4824A** 0.98 1.06 315(A,J)AV066135 CNPV*6024A** 0.98 1.05 315(A,J)AV066135 CSPH*4812A** 0.98 1.05 315(A,J)AV066135 CSPH*6012A** 0.98 1.03 315(A,J)AV066135
Heating Indoor Model Capacity Power Furnace Model
CAP**4824A** 0.98 1.06 315(A,J)AV066155 CAP**6024A** 0.98 1.04 315(A,J)AV066155
CNPH*4821A** 0.98 1.05 315(A,J)AV066155 CNPH*6024A** 0.98 1.04 315(A,J)AV066155 CNPV*4824A** 0.98 1.05 315(A,J)AV066155 CNPV*6024A** 0.98 1.04 315(A,J)AV066155 CSPH*4812A** 0.98 1.05 315(A,J)AV066155 CSPH*6012A** 0.98 1.03 315(A,J)AV066155
CAP**4821A** 0.98 1.09 355AAV060080 CAP**6021A** 0.99 1.08 355AAV060080
CNPH*4821A** 0.98 1.08 355AAV060080 CNPH*6024A** 0.98 1.07 355AAV060080 CNPV*4821A** 0.98 1.08 355AAV060080 CSPH*4812A** 0.98 1.07 355AAV060080 CSPH*6012A** 0.98 1.06 355AAV060080
CAP**4821A** 0.98 1.08 355AAV060100 CAP**6021A** 0.98 1.06 355AAV060100
CNPH*4821A** 0.98 1.08 355AAV060100 CNPH*6024A** 0.98 1.06 355AAV060100 CNPV*4821A** 0.98 1.08 355AAV060100 CSPH*4812A** 0.98 1.07 355AAV060100 CSPH*6012A** 0.98 1.05 355AAV060100
CAP**4824A** 0.98 1.08 355AAV060120 CAP**6024A** 0.98 1.06 355AAV060120
CNPH*4821A** 0.98 1.08 355AAV060120 CNPH*6024A** 0.98 1.06 355AAV060120 CNPV*4824A** 0.98 1.08 355AAV060120 CNPV*6024A** 0.98 1.06 355AAV060120 CSPH*4812A** 0.98 1.07 355AAV060120 CSPH*6012A** 0.98 1.05 355AAV060120
See notes on pg. 31
