31
HEAT PUMP HEATING PERFORMANCE CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
-- 3 7 17 27 37 47 57 67
EDB CFM
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ*
265ANA060-- B Outdoo r Section With FX4CNF 060 Indoor Section
65
1750 25.04 23.04 3.66 30.87 28.37 3.82 37.09 33.82 3.99 43.79 38.89 4.18 51.53 46.90 4.41 59.82 59.82 4.61 68.25 68.25 4.88 76.95 76.95 5.17
2000 25.48 23.44 3.69 31.34 28.80 3.84 37.58 34.27 4.00 44.35 39.39 4.17 52.32 47.61 4.35 60.19 60.19 4.54 68.33 68.33 4.77 72.60 72.60 4.88
2250 25.87 23.80 3.74 31.76 29.18 3.88 38.03 34.67 4.02 44.84 39.82 4.18 52.89 48.13 4.34 60.29 60.29 4.51 66.89 66.89 4.68 68.93 68.93 4.71
70
1750 24.33 22.39 3.82 30.20 27.76 3.99 36.48 33.26 4.18 43.16 38.33 4.39 50.61 46.05 4.62 59.08 59.08 4.83 67.48 67.48 5.11 76.32 76.32 5.42
2000 24.77 22.79 3.86 30.68 28.20 4.02 36.99 33.72 4.19 43.72 38.83 4.37 51.39 46.77 4.58 59.50 59.50 4.76 67.66 67.66 5.00 73.14 73.14 5.16
2250 25.17 23.16 3.91 31.11 28.59 4.05 37.43 34.13 4.21 44.21 39.27 4.38 52.04 47.36 4.55 59.73 59.73 4.73 67.52 67.52 4.94 69.87 69.87 4.98
75
1750 23.57 21.68 3.99 29.51 27.12 4.18 35.83 32.67 4.38 42.51 37.75 4.59 49.79 45.31 4.83 58.34 58.34 5.06 66.67 66.67 5.35 75.53 75.53 5.68
2000 24.01 22.09 4.03 29.99 27.56 4.20 36.35 33.14 4.38 43.07 38.26 4.58 50.52 45.97 4.79 58.80 58.80 4.99 66.99 66.99 5.24 73.35 73.35 5.44
2250 24.41 22.46 4.08 30.42 27.95 4.23 36.81 33.56 4.40 43.57 38.70 4.58 51.16 46.56 4.77 59.10 59.10 4.95 67.03 67.03 5.18 70.50 70.50 5.26
Heating Indoor Model Capacity Power Furnace Model
*FX4CN(B,F)060 1.00 1.00
FE4ANB006 0.99 1.00
FV4BNB006 0.99 1.00
FY4ANB060 1.01 1.05
CAP**6021A** 0.99 1.04
CAP**6024A** 1.01 1.04
CNPH*6024A** 1.01 1.04
CNPV*6024A** 1.01 1.04
CSPH*6012A** 1.01 1.02
CAP**6021A** 0.99 1.04 315(A,J)AV060110
CNPH*6024A** 0.98 1.05 315(A,J)AV060110
CSPH*6012A** 0.98 1.02 315(A,J)AV060110
CAP**6024A** 0.99 1.04 315(A,J)AV066135
CNPH*6024A** 0.99 1.05 315(A,J)AV066135
CNPV*6024A** 0.99 1.05 315(A,J)AV066135
CSPH*6012A** 0.98 1.01 315(A,J)AV066135
CAP**6024A** 0.98 1.02 315(A,J)AV066155
CNPH*6024A** 0.99 1.04 315(A,J)AV066155
CNPV*6024A** 0.99 1.04 315(A,J)AV066155
CSPH*6012A** 0.98 1.00 315(A,J)AV066155
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* The Btuh heating capacity values shown are net integrated values from which the defrost effect has been subtracted. The Btuh heating from supplement heaters should be added to those values to obtain total system capacity.
{ The kW values include the compressor, outdoor fan motor, and indoor blower motor. The kW from supplement heaters shou l d be added to these valu es to obtain total system kilowatts.
EDB —EnteringDryBulb
265A
