Specifications
Temperature Ranges
Heat: 50to88° F (10 to 31° C) by default,
adjustable from 50 to 90° F (10 to 32° C)
Cool: 52to90° F(11to32° C) by default,
adjustable from 50 to 90° F (10 to 32° C)
Display: 40 to 100° F(5to37° C)
Sensitivity: +/-- 1° F(0.5° C)
Operating 32 to 130° F(0to55° C)
Humidity Range
Display: 20 to 90% R.H.
Sensitivity: +/-- 5% R.H.
Operating: 5 to 95% R.H. (non--condensing)
Dimensions
Thermostat: 5.5” W x 3.25” H x 1” D
(139.5mm W x 82.5mm H x 25mm D)
Power Consumption
24VAC (3VA maximum)
