Fig. 4–Light Commercial Application-Doctor’s Office (unzoned)
A00121
Waiting Room Room 1 Room 2 Room 3 Room 4
Office Office Lab
Bath
Bathrooms
Fig. 5–Light Commercial Application-Doctor’s Office (zoned)
A00122
Room 1 Room 2 Room 3 Room 4
Office Office Lab
Bath
Bathrooms
Waiting Room
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
