Line Frequency (Models 233 & 235 only)
Function Sensitivity (Sine RMS) Range
60mV, 600mV 50mV 10Hz - 50kHz
6V 5V 10Hz - 50kHz
60V 10V 10Hz - 50kHz
600V 50V 10Hz - 1kHz
1000V 500V 10Hz - 1kHz
VFD 600V 50V 10Hz - 1kHz
VFD 1000V 500V 10Hz - 1kHz
600A, 6000A 500A
10Hz - 5kHz
60mA, 600mA 50mA 10Hz - 5kHz
6A, 10A 8A 50Hz - 1kHz
Accuracy: 0.03% + 2d
Non-Contact EF-Detection
Bar-Graph
Indication
EF-H (Hi Sensitivity) EF-L (Lo Sensitivity)
Typical Voltage (Tolerance)
- 10V (3V ~ 19V) 40V (16V ~ 71V)
- - 20V (10V ~ 38V) 80V (32V ~ 142V)
- - - 40V (21V ~ 79V) 160V (63V ~ 285V)
- - - - 80V (40V ~ 156V) 300V (105V ~ 608V)
- - - - - 160V (>80V) 500V (>300V)
Indication: Bar-graph segments & audible beep tones proportional to the field strength
Detection Frequency: 50/60Hz
Detection Antenna: Top-left end of the meter
Probe-Contact EF-Detection: For more precise indication of live wires, such as
distinguishing between live and ground connections, use direct contact testing with one
single test-probe via the input terminal COM or V. The COM terminal (Black) has the
best sensitivity.
