Typical THD+N Sweep 3BSST
4 ohm 250w
8 ohm 150w
3B SST and 4B SST Series Amplifiers
11
Typical IMD Sweep 3BSST
8 ohm 150w
4 ohm 250w
Graph shows that distortion is
essentially unaffected by load.
2v balanced input shown.
Typical THD+N Sweep 4BSST
4 ohm 500w
8 ohm 3000w
Typical IMD Sweep 4BSST
8 ohm 300w
4 ohm 500w
Graph shows that distortion is
essentially unaffected by load.
2v balanced input shown.
