Bryston B60R - Specifications; General Specifications; Preamplifier Section Specifications; Power Amplifier Section Specifications

B60 INTEGRATED AMPLIFIERS
GENERAL:
DIMENSIONS:
Standard version:
17” x 1.75” x 11” (43.18 x 4.44 x 28cm)
Rack mount version:
19” x 1.75” x 11” (48.26 x 4.44 x 28cm)
WEIGHT:
17 lbs (7.5 kg)
PREAMPLIFIER Section:
FREQUENCY RESPONSE:
20Hz~20kHz +/- .05dB
MAXIMUM OUTPUT:
15 volts
IMD/THD:
<0.005% at 3 volts out
SENSITIVITY:
500mV (High level inputs)
NOISE:
-100dB (Ref. 500mV
in
), 20~20K Hz
POWER AMPLIFIER Section:
OUTPUT POWER:
60 watts/channel into 8 ohms
100 watts/channel into 4 ohms
THD+N:
<0.02% 20Hz~20KHz @ 60 watts
NOISE:
106dB gwlow full output
SLEW RATE:
>60v/uSec
DAMPING FACTOR:
>500 at 20Hz (8 ohms)
POWER BANDWIDTH:
0.5Hz to over 100KHz
SENSITIVITY:
.775v
INPUT IMPEDANCE:
50K ohms
ADDITIONAL SPECIFICATIONS for B60DA/B60RDA DIGITAL INPUTS:
INPUT SAMPLE RATE
:
16kHz to 108kHz.
WORD LENGTH:
16, 18, 20, 24 Bit
DATA FORMAT:
SPDIF standard
THD+N:
< 0.002%, 20Hz~20kHz
ADDITIONAL SPECIFICATIONS for B60P/B60RP PHONO INPUTS:
THD+N:
<0.005%, IM or THD, any frequency or
combination of frequencies from 20-20kHz,
at rated output or below.
NOISE
:
Phono: -80dBA referred to an input of 5 mV
RIAA ACCURACY
:
Within less than +/- 0.05dB from 20~20kHz
SENSITIVITY
:
5mV
SPECIFICATIONS
VARIOUS SPEAKER WIRE TERMINATIONS
AMPLIFIER OUTPUT BINDING POSTS
