LUBRICATION CHART
No PART Lubricant Type of
Lubrication
Daily 250 Miles
(Inclusive)
General
FRAME GROUP
3 Front fork (top) CG-1 (AL) 1 nipple Grease Gun
2 Front fork (centre) CG-1 (AL) 1 nipple Grease Gun
4 Steering Stem (top) CG-1 (AL) 1 nipple Grease Gun
5 Steering Stem (bottom) CG-1 (AL) 2 nipple Grease Gun
7 Steering Head (top) CG-1 (AL) 1 nipple Grease Gun
6 Steering Head (bottom) CG-1 (AL) 1 nipple Grease Gun
8 Saddle nose pivot CG-1 (AL) 1 nipple Grease Gun
11 Front wheel hub CG-1 (AL) Re pack - Re pack w shops every 5000 miles
12 Rear wheel hub CG-1 (AL) Re pack - Re pack w shops every 5000 miles
BRAKE GROUP
9 Brake pedal CG-1 (AL) 1 nipple Grease Gun
16 Brake cam (front) CG-1 (AL) 1 nipple Grease Gun
15 Brake cam (rear) CG-1 (AL) 1 nipple Grease Gun
Bowden control wire OE-30 Oil Can Few Drops
Foot brake linkage OE-30 Oil Can Few Drops
ENGINE GROUP
1 Engine oil tank OE50 5 pints Replenish Replenish Drain & refill at 1000 miles (AO17)
19 Primary chain case OE50 Reservoir Replenish Replenish Drain & refill at 1000 miles (AO17)
1/20 Oil Filters OE50 Wash in petrol every 2000 miles
IGNITION GROUP
Advance Retard Cable etc OE30 Oil Can Few drops
Contact breaker tappet OE30 Oil Can One drop
22 Contact breaker cam CG-1 (AL) Hand smear Slight smear
Generator (drive end) WB-2 Re pack Re pack w shops
21 Generator (commutator end) OE30 Oil Can Few drops
FUEL GROUP
Air cleaner N/A
Carburetter control cables OE30 Oil Can Few drops
Throttle handle bar grip OE30 Oil Can Few drops
TRANSMISSION GROUP
10 Speedometer drive CG-1 (AL) 1 nipple Grease Gun
Speedometer cable OE30 Oil can Few drops
14 Gear box GO-90 1 pint Replenish Drain & refill each 6000 miles No 18
12 Clutch push rod OE-50 Oil can Few drops
Clutch bowden control wire OE30 Oil can Few drops
Clutch handle bar grip OE30 Oil can Few drops
Rear chain OE30 Oil can Few drops Wash in paraffin and soak in oil OE-
50 every 2000 miles. Workshops
5
