Bside ADM02 - Functional Push Button

Fig. 1 Exterior view
1. LCD display 2. ‡ MAX· push button 3. ‡ BACK LIGHT·
push button 4. “HOLD· push button 5. ‡ FUNC· Push
button 6. Rotary Switch (Knob) 7. ‡ V/Ω
/uA/mA/Temp· Input terminal
8. ‡ COM· input terminal 9. ‡ 10A· input terminal
3-2. Functional push button
Push
button
Function
Func
“FUNC” key is the function select key
that acts with trigger. Use the key as
switch of DC/AC current,
Diode/Continuity and ₤ /₦ .
HOLD
Press “HOLD· to enter and exit the hold
mode in any mode. That act with trigger.
MAX
This key is act with trigger. Press this key
once, the maximum value is holding (Will
displays “MAX’ symbol in the LCD).
After pressing the key, A/D will keep
working, and the display value are always
up dated and kept the maximum value.
NOTE: The actual gained value is not the
peak value.
3
