Optional Balancing Transformer Fitting
Optional Security Cover
8.3 Optional
Balancing
Transformer Fitting
The two VDRs are mounted on a small circuit board attached to the
rear of the 120/240v selector switch and are specified as Philips 2322-
594-61312 (Max voltage 130v). Please ensure the unit is disconnected
from the mains power before attempting removal.
Provision is made internally to fit balancing transformers to both the
electronically balanced inputs and outputs.
INPUT TRANSFORMER KIT IS BSS PART No:
Z-TIX1KIT-01 for the FCS-930
Z-TIX2KIT-01 for the FCS-960
OUTPUT TRANSFORMER KIT IS BSS PART No:
Z-TOX1-KIT-01 for the FCS-930
Z-TOX2-KIT-01 for the FCS-960
The transformers are easily fitted onto the printed circuit board adjacent
to the respective output connectors. Please ensure correct orientation
and removal of links:
LINK REMOVAL CHN 1 CHN 2 (FCS-960 only)
INPUT TX 1, 2 7, 8
OUTPUT TX 3, 4 5, 6
