28/39 ekr CON 600, ekr CON 600 net – Application with Wide Array Edge Sensors
9 Operation
9.1 Safety Instructions
WARNING
Severe injuries and material damage due to faulty operation!
►
Ensure that operating is carried out by qualified and adequately
instructed personnel only.
All of the following chapters presuppose that you have
sufficient knowledge of the basic operating steps, see
operating manual of the ekr CON 600, ekr CON 600 net
controller. All safety instructions listed there also apply
for the following chapters.
►
Please also read and follow all safety instructions contained in
the operating manual for the ekr CON 600, ekr CON 600 net
controller (document number MD.542).
9.2 Operation Display
This manual only describes the operation display for wide array
edge sensors.
For a description of all display elements, please refer to the oper-
ating manual for the ekr CON 600, ekr CON 600 net controller
(document number MD.542).
9.2.1 Operation Display Wide Array Edge Sensors (Sensor 1/2)
The operation displays for Sensor1 and Sensor2 only appear if the
respective wide array edge sensors are connected to the controller.
The appearance of the operation display depends on the number of
connected wide array edge sensors.
Operation with one
wide array edge sensor
Fig.11: Operation with one wide array edge sensor (connected as Sensor 1)
