Setup Description Range Default
P5.01
Output function
Programmable 1
See list “Programmable
output functions”
S.GE
Start generator
P5.02
Output function
Programmable 2
See list “Programmable
output functions”
RDY
ATS Ready
P5.03
Output function
Programmable 3
See list “Programmable
output functions”
ALA
Global alarm
Function Description Notes
OFF
OFF Output not used
S.GE
Consent to start up the generator
When closed, the generator must be inactive.
Contact opens to start generator.
If the unit is not powered, the generator starts
RDY
Automatic transfer switch ready
Indicates unit automatically and without alarms,
ready to start operating
ALA
Global alarm De-energizes in case of an alarm
MCM
Minimum coil
Main line
Main line switch voltage minimum opening
coil command
MCS
Minimum coil
Secondary line
Secondary line switch voltage minimum opening
coil command
L.SH
Non-priority load disconnection
Disconnection of the non-priority loads that are
not powered by the secondary line branch.
It is also controlled on the secondary line.
Contact which is closed before the secondary
line closing command and opened before the
main line closing command
Programmable output functions
P6.01…P6.04 They determine the transmission format and the protocol used on communication port
RS-232
P6.05…P6.08 They determine the transmission format and the protocol used on communication port
RS-485, available only on M7000CB/EVO
7.8 P5 menu - Programmable outputs
Setup Description Range Default
P6.01
Serial address RS-232 1…245 01
P6.02
Speed (baudrate) RS-232
240 = 2400
480 = 4800
960 = 9600
19.2 = 19200
38.4 = 38400
960
P6.03
Protocol RS-232
Rtu = Modbus RTU
ASC = Modbus ASCII
RTU
P6.04
Parity RS-232
No = None
EVE = Even
Odd = Odd
No
P6.05
Serial address RS-485 1…245 01
P6.06
Speed (baudrate) RS-485
240 = 2400
480 = 4800
960 = 9600
19.2 = 19200
38.4 = 38400
960
P6.07
Protocol RS-485
Rtu = Modbus RTU
ASC = Modbus ASCII
RTU
P6.08
Parity RS-485
No = None
EVE = Even
Odd = Odd
No
7.9 P6 menu - Serial communication
The highlighted param-
eters are included only in
version M7000CB/EVO
