Menu Description
P0
System nominal data
P1
General Data
P2
Main line voltage control
P3
Secondary line voltage control
P4
Programmable inputs
P5
Programmable outputs
P6
Communication port
Setup Description Range Default
P0.01 B
Nominal voltage Ue 100 … 690 VAC 380 VAC
P0.02 B
Transformation ratio TV 1.00 … 9.99 1.00
P0.03 B
Type of connection
3Ph = Three-phase
2PH = Two-phase
1Ph = Single-phase
3Ph
P0.04 B
Nominal frequency Fe
50H = 50Hz
60H = 60Hz
50Hz
P0.05 B
Nominal battery voltage
OFF = No battery
12 = 12 VDC
24 = 24 VDC
48 = 48 VDC
OFF
P0.01 Nominal voltage used for calculating the thresholds, which are expressed in Un percentage
P0.02 Leave default setup in case a TV is not used
P0.04 Nominal frequency used as a reference for calculating the frequency thresholds
P0.05 Used for the alarms on the battery voltage
7.2 Table of menus
