BÜCHI Distillation Unit K-3149 Appendix
9 Appendix
9.2 Materials used
9.1 Technical data
Dimensions (Width x Height x Depth) 245 x 420 x 220 mm
Nominal voltage 230 V, 50/60 Hz
Mains voltage tolerance +10 % / -15 %
Power rating 1800 Watt
Power consumption approx. 8 Ampère
Volume supply tank 10 L
Volume sample tubes 300 ml (Standard)
500 ml (Special)
Weight (netto) approx. 16 kg
Dimensions 320 x 695 x 320 mm
Ambient temperature Operation: +10 to +40° C
Storage: - 40 bis +70° C *
Steam or distillate flow capacity approx. 30ml/min
Overvoltage Category II
Pollution degree 2
*Note: If being stored at temperatures below +5° C, remove all liquid from the unit.
Due to the danger of frost, the steam generator, cooler, hoses etc. must all be emptied !
Caution: The steam generator may only be emptied by authorized service personnel.
Table 6: Technical data
Part Material Material code
Housing Zinkor ST 1203 ELVZ
Glass parts Borosilicate glass 3.3 DIN/ISO 3585
Front protection Polystyrene PS
Protective door Polymethylmethacrylate PMMA
Contact guard AIMgSi1
Isolation steam generator Alkaline earth silicate fibers X-607
Housing steam generator Polysulphones with 20% fiberglass PSU/20% GF
Rubber bung Hypalon CSM
Distributor Ethylene-propylene rubber EPDM
Metals X5CrNi1810 1.4301
X10CrNiS189 1.4305
Hoses Polytetrafluorethyleen PTFE
Silicone
Table 7: Materials used
