Table 10-1: Spare parts on the exploded instrument view
Position Product Order number Position Product Order number
1 Tray for adsorption storage (with
screw)
11057332 23 Swirl disc 037821
2 Anti-seismic-tie-down - 24 Spacer tube 037852
3 Silencer unit
(filled with polyester fibres)
11056985 25 Swirl disc holder 037851
4 Neoprene hose (8/2 x 250) 11056456 26 Lip gasket
EPDM (resistant against bases)
FPM (resistant against acids)
037874
038064
5 Hose clamp (10 - 16 mm) 043297 27 Cover of neutralization vessel 11057139
6 Receiving vessel 11057153 28 O-Ring 24 x 2.5
(with hose connector adapter)
037928
7 Screw cap GL 14 (Set of 10
pcs.)
041956 29 Hose connector adapter M20 GL
14
037777
8 + 7 Connector straight for GL 14
with FPM sealing (set of four,
including screw caps)
040296 30 + 7 Connector bent for GL 14
(set of four, including screw caps)
040295
9 Rubber strap 11059813 31 Reaction vessel, 1.0 L 037797
10 Condenser S35 11057152 32 Gasket ring 037925
11 Hose condenser /
washing solution (FEP)
11057155 33 Screw cap SVL 42 003551
12 Carrier plate for condeser - 34 Introduction tube assembly 037778
13 Screws for carrier plate (M4x16) - 35 Hose reaction / pump (FEP) 11057157
14 Catchpot clip S35 003275 36 Hose adsorption / reaction (FEP) 11057156
15 Hose connection S19 (ball joint) 11057159 37 Axial Gasket ring 049485
16 Ball joint clamp 11057149 38 Adapter piece for adsorption 11057147
17 + 7 Gasket FEP (GL 14) (set of 10,
incl. screw caps)
041999 39 Gasket SVL 42 x 30 PTFE 003575
18 Receiving vessel with cock
(TKN-set)
11056979 40 Adsorption vessel 037774
19 Hose clamp (10 - 16 mm) 043297 41 Gasket SVL 22 x 16 PTFE
(with silicone bearing)
002070
20 Tube for TKN-set (1.5 m, 8/12) 020136 42 Adapter SVL 22 / GL 14 037972
21 Neutralization vessel (P+G) 11057138 43 Hose adsorption / pump 11057154
22 Nut M20 037855
