2
Product description
Logano G115 WS US/CA – 6 720 813 418 (2019/09)6
2.5 Product description
The boiler is a low-temperature oil-fired appliance with automatic
control panel or aquastat for boiler water temperature.
The boiler consists of:
Boiler heat exchanger with insulation
Boiler jacket
Control panel or aquastat
The controls monitor and control all electrical boiler components.
The boiler can alternatively be fitted with a simple aquastat control.
The boiler jacket prevents heat loss and acts as a noise insulator.
The boiler heat exchanger transfers the heat generated by the burner to
the heating water. The insulation prevents energy loss.
Suitable burners
Fig. 1 Boiler without burner
[1] Control panel R2107 (sold separately)
[2] Boiler jacket
[3] Boiler heat exchanger with insulation
[4] Burner door
[5] Burner door panel
CAUTION: Risk of system damage from use of incorrect
burner.
Only the burner provided may be employed with this
boiler.
6 720 615 225-01.1RS
1
2
3
4
5
