Bugera BC30-212 - Circuit Protector

Parts ListBC30-212
Page 11
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
35 1.0000 PC CAP E;47uF;35V;20%;PITCH:2mm5;5mm x 11mm;PRECUT:3mm2 -
0/+0mm2;105C
[P0738:04: {1.0}(C7)] *NOT available in DP
36 1.0000 PC CAP E;47uF;50V;PITCH:2mm5;6.3mmx11mm;PRECUT:3mm2 -
0/+0mm2
[P0738:04: {1.0}(C59)] *NOT available in DP
Circuit Protector
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 10.0000 PC R21-15201-52000 B21-15201-52000 FUSE CLIP;2 A;V;ZINC PLATING;250V;SERIES;520;FUSE;250 V;PLATING [P0738:02: {10.0}(F1-F5)]
2 2.0000 PC R22-01512-63001 B22-01512-63001 FUSE;630mA;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0738:02: {2.0}(F1-F2)]
3 1.0000 PC R22-01514-10001 B22-01514-10001 FUSE;10A;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0738:02: {1.0}(F5)]
4 1.0000 PC B22-01613-10001 FUSE;1A0;250V;FAST BLOW;H-TYPE;5mm x 20mm [P0738:04: {1.0}(F6)]
5 2.0000 PC R22-01513-16001 B22-01513-16001 FUSE;1A6;250V;SLOW BLOW;H-TYPE;5mm x 20mm [P0738:02: {2.0}(F3-F4)] (UL, JP, BR, HM, SH)
6 1.0000 PC R22-01513-31501 B22-01513-31501 FUSE;3A15;250V;SLOW BLOW;H-TYPE;5mm x 20mm [: {1.0}(F1,PSU6)] (UL, JP, BR, HM, SH)
7 3.0000 PC R22-01513-16001 B22-01513-16001 FUSE;1A6;250V;SLOW BLOW;H-TYPE;5mm x 20mm PSU6:F1] (EU, UK, SAA, AR, RU)
8 1.0000 PC R22-01513-31501 B22-01513-31501 FUSE;3A15;250V;SLOW BLOW;H-TYPE;5mm x 20mm [: {1.0}(F1,PSUI6)]
9 3.0000 PC R22-01513-16001 B22-01513-16001 FUSE;1A6;250V;SLOW BLOW;H-TYPE;5mm x 20mm [: {1.0}(F1,PSU6)]
10 3.0000 PC R22-01513-16001 B22-01513-16001 FUSE;1A6;250V;SLOW BLOW;H-TYPE;5mm x 20mm [: {1.0}(F1,PSU6)]
Connector
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC R84-00000-01620 B84-00000-01620 AMP TERMINAL;BRASS W TIN;7205A-BS-2
2 10.0000 PC R84-19056-06015 B84-19056-06015 CONNECTOR;TERMINAL;BRASS W TIN;AWG16-22;JS-4008-T
3 14.0000 PC R84-22000-06018 B84-22000-06018 CRIMP TERMINAL;PITCH:3mm96;AWG18-22;A3963TOP-2
4 33.0000 PC R84-25016-06014 B84-25016-06014 CRIMP TERMINAL;PITCH:2mm0;AWG24-30;A2008TOP-2
5 2.0000 PC R84-30000-06293 B84-30000-06293 JACKET;FOR 205 TERMINAL.;DIA:4mm
6 2.0000 PC R84-30046-39242 B84-30046-39242 CONNECTOR;AMP CONN TERMINAL;MATERIAL:PAPER
FIBRE;QUADRUPLE;(BWF38703003-TERMINAL-REVA.DWG)
7 2.0000 PC R84-30060-06009 B84-30060-06009 JACKET;FOR 6mm35 AMP
CONNECTOR;PVC;STRAIGHT;DIAMETER:4mm
8 2.0000 PC B84-32050-05839 CRIMP CONNECTOR;AMP;RECEPTABLE;6mm3 x 7mm5;AWG 14-
18;WIRE MOUNT;STRAIGHT;250 SERIES
9 10.0000 PC R84-39000-03120 B84-39000-03120 CONNECTOR;AMP;PCB;PCB MOUNT;PITCH:5mm;WIDTH:6mm3 [P0738:01: {1.0}(X69)]
10 1.0000 PC R84-42050-00155 B84-42050-00155 CRIMP CONNECTOR;LUG;INNER DIA:4mm3;AWG 14-18;WIRE
MOUNT;STRAIGHT
11 1.0000 PC B93-60010-41238 CONNECTOR;BARE JUMPER;WIRE DIAMETER:1mm;LENGTH:15mm [P0738:02: {1.0}(J1)]
Diode
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC DIODE;1N4148;DO35 [P0738:04: {1.0}(D3)] *NOT available in DP
2 12.0000 PC DIODE;1N4007;DO41 [P0738:02: {10.0}(D6-D15)] *NOT available in DP
3 2.0000 PC DIODE;LL4148;LL34;TEMIC OR FC;SMD [P0738:05: {2.0}(D1-D2)] *NOT available in DP
4 2.0000 PC DIODE;ZPD15V0;DO35;TEMIC OR FC [P0738:05: {2.0}(D17-D18)] *NOT available in DP
