Bugera BC30-212 - Speaker Part

Parts ListBC30-212
Page 20
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
36 1.0000 PC Y04-12000-03091 I04-12000-03091 THERMISTOR;NTC;20ohm;+/- 20%;4A;DIA:;PITCH:7mm5;(THINKING
SCK-20200MSY)
[PSU6:00: {1.0}(R1)] (EU, UK, SAA, AR, RU)
Potentiometer
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC Y03-00000-18521 I03-00000-18521 POTENTIOMETER;1 Mohm;D;20 %;MONO;0.05W;TORQUE:50-
90gf.cm;SHAFT:39.6mm
[P0738:01: {1.0}(VR6)]
2 3.0000 PC I03-00000-18918 POTENTIOMETER;1 Mohm;A;20 %;MONO;0.05W;TORQUE:50-
90gf.cm;SHAFT:39.6mm
[P0738:01: {3.0}(VR2-VR4)]
3 1.0000 PC I03-00000-18919 POTENTIOMETER;250 kohm;A;12 %;MONO;0.05W;TORQUE:50-
90gf.cm;SHAFT:39.6mm
[P0738:01: {1.0}(VR5)]
4 1.0000 PC I03-00000-24052 POTENTIOMETER;500 kohm;A;12 %;MONO;0.05W;TORQUE:50-
90gf.cm;SHAFT:39.6mm
[P0738:01: {1.0}(VR1)]
5 1.0000 PC I03-27245-05868 POTENTIOMETER;47Kohm;TAPER:B;MONO;ROUND-
SHAFT:22MM;W/O CC;40-70gf;HIGH TORQUE;(DELTA
R0911NOAV1B473EH10A1)
[P0738:04: {1.0}(VR7)]
Speaker Part
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC X77-00000-85774 H77-00000-85774 WOOFER;8 OHM;P0B2G;TS-12G320A8;12 inch;80 watts
2 1.0000 PC H77-00000-85775 WOOFER;8 OHM;P0B2H;TS-12G400B8;12 inch;100 watts
3 2.0000 PC H79-00000-03038 DAMPER;CONEX;TRANSPARENT BLUE;LS-DP125CN01;REVA
4 1.0000 PC H79-00100-02378 MAGNET;MG156FE55A;MATERIAL:Y30;156mm*60mm*20mm;DST.N
O:001;DPT.NO:02378;(LS-MG156FE55A-REVA.DWG)
5 1.0000 PC X79-00100-02653 H79-00100-02653 GASKET;GA305P6_5A;MATERIAL:BLACK PAPER;OUTER
DIAMETER:305mm;THICKNESS:6mm5;DST.NO:001;DPT.NO:02653;(L
S-GA305P6_5A-REVA.DWG)
6 1.0000 PC X79-00100-03201 H79-00100-03201 GASKET;GA304P6A;MATERIAL:PAPER;BLACK;DIAMETER:304mm;HEI
GHT:6mm;DST.NO:001;DPT.NO:03201;(LS-GA304P6A-REVA.DWG)
7 1.0000 PC H79-00100-06312 MAGNET;MG135FE26A;MATERIAL:Y30;DIA
135x56x15H;DST.NO:001;DPT.NO:06312;(LS-MG135FE26A-
REVA.DWG)
8 2.0000 PC H79-00100-06315 DUST CAP;DC95CL02A;MATERIAL:BLACK CLOTH;OUTER
DIAMETER:95mm;HEIGHT:18mm5;DST.NO:001;DPT.NO:06315;(LS-
DC95CL02A-REVA.DWG)
9 1.0000 PC H79-00100-14846 VOICE COIL; VC37_5NX6_8A;DST.NO:001;DPT.NO:14846;(LS-
VC37_5NX6_8A[R]-REVA.DWG)
10 1.0000 PC H79-00100-14847 CONE PAPER, CP297P75_5D;DST.NO:001;DPT.NO:14847;(LS-
CP297P75_5D[R]-REVA.DWG)
11 1.0000 PC H79-00100-14848 VOICE COIL; VC37_5K7A;DST.NO:001;DPT.NO:14848;(LS-
VC37_5K7A[R]-REVA.DWG)
12 1.0000 PC H79-00100-14860 CONE PAPER, CP297P75_5E;DST.NO:001;DPT.NO:14860;(LS-
CP297P75_5E[R]-REVA.DWG)
