Resistor
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 2.0000 PC RESISTOR;CARBON;470ohm;5%;0W1;SMD805 [P0738:05: {2.0}(R3,R7)] *NOT available in DP
2 1.0000 PC RESISTOR;CARBON;22Kohm;5%;0W1;SMD805 [P0738:05: {1.0}(R4)] *NOT available in DP
3 1.0000 PC RESISTOR;CARBON;47Kohm;5%;0W1;SMD805 [P0738:05: {1.0}(R5)] *NOT available in DP
4 3.0000 PC RESISTOR;CARBON;68Kohm;5%;0W1;SMD805 [P0738:05: {3.0}(R2,R6,R8)] *NOT available in DP
5 1.0000 PC RESISTOR;CARBON;680Kohm;5%;0W1;SMD805 [P0738:05: {1.0}(R1)] *NOT available in DP
6 2.0000 PC RESISTOR;CARBON;47ohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:04: {2.0}(R15-R16)] *NOT available in DP
7 1.0000 PC RESISTOR;CARBON;100ohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:05: {1.0}(R106)] *NOT available in DP
8 46.0000 PC RESISTOR;CARBON;270ohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:03: {18.0}(R1-R18)] *NOT available in DP
9 2.0000 PC RESISTOR;CARBON;1Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:05: {2.0}(R111,R113)] *NOT available in DP
10 4.0000 PC RESISTOR;CARBON;1Kohm5;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:02: {4.0}(R31,R42,R51-R52)] *NOT available in DP
11 1.0000 PC RESISTOR;CARBON;4Kohm7;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:01: {1.0}(R77)] *NOT available in DP
12 3.0000 PC RESISTOR;CARBON;10Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:04: {2.0}(R13-R14)] *NOT available in DP
13 1.0000 PC RESISTOR;CARBON;15Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:05: {1.0}(R107)] *NOT available in DP
14 5.0000 PC RESISTOR;CARBON;68Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:01: {4.0}(R79-R80,R84,R87)] *NOT available in DP
15 2.0000 PC RESISTOR;CARBON;100Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:05: {2.0}(R102-R103)] *NOT available in DP
16 2.0000 PC RESISTOR;CARBON;120Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:02: {1.0}(R36)] *NOT available in DP
17 2.0000 PC RESISTOR;CARBON;470Kohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:02: {1.0}(R41)] *NOT available in DP
18 4.0000 PC RESISTOR;CARBON;1Mohm;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:01: {1.0}(R76)] *NOT available in DP
19 5.0000 PC RESISTOR;CARBON;5Mohm1;5%;0W25;LEAD WIRE;HORIZONTAL 26-
6mm
[P0738:01: {5.0}(R81,R86,R94-R96)] *NOT available in DP
20 2.0000 PC RESISTOR;CARBON;4ohm7;5%;1W;LEAD WIRE [P0738:02: {2.0}(R56,R58)] *NOT available in DP
21 2.0000 PC RESISTOR;CARBON;47ohm;5%;1W;LEAD WIRE [P0738:04: {2.0}(R22-R23)] *NOT available in DP
22 1.0000 PC RESISTOR;CARBON;1Kohm2;5%;1W;LEAD WIRE [P0738:02: {1.0}(R32)] *NOT available in DP
23 4.0000 PC RESISTOR;CARBON;1Kohm5;5%;1W;LEAD WIRE [P0738:04: {4.0}(R17-R20)] *NOT available in DP
24 1.0000 PC RESISTOR;CARBON;4Kohm7;5%;1W;LEAD WIRE [P0738:02: {1.0}(R25)] *NOT available in DP
25 1.0000 PC RESISTOR;CARBON;10Kohm;5%;1W;LEAD WIRE [P0738:01: {1.0}(R93)] *NOT available in DP
26 1.0000 PC RESISTOR;CARBON;47Kohm;5%;1W;LEAD WIRE [P0738:02: {1.0}(R33)] *NOT available in DP
27 2.0000 PC RESISTOR;CARBON;100Kohm;5%;1W;LEAD WIRE [P0738:01: {1.0}(R82)] *NOT available in DP
28 3.0000 PC RESISTOR;CARBON;220Kohm;5%;1W;LEAD WIRE [P0738:01: {1.0}(R83)] *NOT available in DP
29 4.0000 PC RESISTOR;CARBON;1Mohm;5%;1W;LEAD WIRE [P0738:02: {2.0}(R29-R30)] *NOT available in DP
30 1.0000 PC RESISTOR;METAL;56Kohm;1%;1W;LEAD WIRE [P0738:02: {1.0}(R35)] *NOT available in DP
31 5.0000 PC RESISTOR;METAL;100Kohm;1%;1W;LEAD WIRE [P0738:02: {5.0}(R26,R28,R34,R43,R55)] *NOT available in DP
32 1.0000 PC RESISTOR;METAL;220Kohm;1%;1W;LEAD WIRE [P0738:02: {1.0}(R40)] *NOT available in DP
33 4.0000 PC RESISTOR;CEMENT;100ohm;5%;5W;LEAD WIRE;AXIAL [P0738:04: {4.0}(R9-R12)] *NOT available in DP
34 3.0000 PC RESISTOR;CEMENT;22Kohm;5%;5W;LEAD
WIRE;RADIAL;PITCH:5mm;PRECUT:3mm1+/-0mm5
[P0738:02: {3.0}(R27,R37,R57)] *NOT available in DP
35 1.0000 PC Y04-11000-00189 I04-11000-00189 THERMISTOR;NTC;10ohm;15%;6A;DIA:;PITCH:10mm;(BQ 10D2-18
LD)
[PSU6:00: {1.0}(R1)] (UL, JP, BR, HM, SH)
