Bugera BC30-212 - Page 15

Parts ListBC30-212
Page 15
Metal Part
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC A60-00100-06313 METAL;TOP PLATE;TP125S02A;DIA 125x39.4x6H;DIA 60-
4xM5;DST.NO:001;DPT.NO:06313;(LS-TP125S02A-REVA.DWG)
2 1.0000 PC A62-00000-86271 METAL;P0B21;STEEL 1.0mm;BLUE;FRAME;FR307S02F
3 1.0000 PC A62-00000-86290 METAL;P0B29;STEEL 1.0mm;BLUE;FRAME;FR308S02D
4 1.0000 PC A65-00000-01580 METAL;P0738;ALU 1.2mm;COVER;PUNCHING AND BENDING;BLACK
ANODIZED;BLACK;P0738-TUBE_COVER-REVB.idw
5 1.0000 PC A65-00000-05174 METAL;P0738;SECC 0.5mm;CASE;STAMPING;P0738-MET_LED_CASE-
REVB
Rework the material on
order.
6 1.0000 PC A65-00001-23804 METAL;YOKE;P0947;MATERIAL:STEEL, LOW CARBON;PLATING
WHITE ZINC;LS-TY125S02C
7 1.0000 PC A65-00001-24986 METAL;YOKE;P0948;MATERIAL:STEEL, LOW CARBON;PLATING
WHITE ZINC;LS-TY145S02N
8 1.0000 PC A65-00100-12661 METAL;ALU SHEET;P0738;DST.NO:001;DPT.NO:12661;(P0738-
MET_ALU_SHEET-REVA.DWG)
9 1.0000 PC A65-00100-14842 METAL, TOP PLATE , TP145S02E;DST.NO:001;DPT.NO:14842;( LS-
TP145S02E[R]-REVA.DWG)
10 4.0000 PC A65-00300-09238 PLATE;TUBE HOLDER;AC108;DST.NO:003;DPT.NO:09238;(AC108-
TUBE-HOLDER-PLATE-REVC.DWG)
11 8.0000 PC Q65-02000-04400 A65-02000-04400 METAL;CORNER;GX112;DWG.NO:04400;(R20-GX112-CORNER-
REVB.DWG)
12 1.0000 PC A65-09000-25912 METAL;FAN GUARD;DIAMETER:80mm;TYP:G;NO:01;SPEC.NO:25912
13 1.0000 PC J02-00000-00571 METAL;P0738;SECC
1.6mm;CASE;STAMPING;SPRAYING;BLACK;P0738-METAL_CASE
14 1.0000 PC A65-00000-05174 METAL;P0738;SECC 0.5mm;CASE;STAMPING;P0738-MET_LED_CASE-
REVB
(EU, UL, JP, UK, SAA, BR, AR,
HM, SH)
