Cable
Quantity Unit S.Sku M.Sku Description Reference Designators Notes
1 1.0000 PC A81-00000-01100 WIRE HARNESS;AWG:26;UL1533;2 MM;2;COMMON;50 MM;GREY [P0738:02: {1.0}(X45)]
2 1.0000 PC A81-00000-02255 WIRE HARNESS;AWG:26;UL1007;2 MM;COMMON;180 MM;RD/BK;X-
P1018;HM-02
[P0738:03: {1.0}(X1)]
3 1.0000 PC A81-00000-02258 WIRE HARNESS;AWG:26;UL1007;2 MM;COMMON;270 MM;RD/BK;X-
P1018;HF-02
[P0738:01: {1.0}(X70)]
4 1.0000 PC A81-00000-02260 WIRE HARNESS;AWG:26;UL1007;2 MM;COMMON;480 MM;RD/BK;X-
P1018;HF-02
[P0738:04: {1.0}(X18)]
5 1.0000 PC A81-00000-04678 WIRE HARNESS;AWG:18;UL1015;3.96 MM;3;COMMON;150
MM;RD/BK
6 1.0000 PC A81-00000-04679 WIRE HARNESS;AWG:26;UL1533;2 MM;2;COMMON;60 MM;BLACK [P0738:02: {1.0}(X52)]
7 1.0000 PC A81-00000-04680 WIRE HARNESS;AWG:26;UL2468;2 MM;4;COMMON;60 MM;ALL
BLACK PIN1 RED
[P0738:02: {1.0}(X40)]
8 1.0000 PC A81-00000-04681 WIRE HARNESS;AWG:26;UL1533;2 MM;3;COMMON;80 MM;BLACK [P0738:02: {1.0}(X36)]
9 1.0000 PC A81-00000-04682 WIRE HARNESS;AWG:26;UL2468;2 MM;3;COMMON;120 MM;PIN1
MARKING
[P0738:05: {1.0}(X3)]
10 2.0000 PC A81-00000-04683 WIRE HARNESS;AWG:26;UL2468;2 MM;2;COMMON;160 MM;RD/BK [P0738:02: {2.0}(X37,X43)]
11 1.0000 PC A81-00000-04684 WIRE HARNESS;AWG:26;UL2468;2 MM;3;COMMON;220 MM;ALL
BLACK PIN1 RED
[P0738:05: {1.0}(X9)]
12 1.0000 PC A81-00000-04685 WIRE HARNESS;AWG:18;UL1015;3.96 MM;3;COMMON;230
MM;RD/BK
13 1.0000 PC A81-00000-04686 WIRE HARNESS;AWG:26;UL2468;2 MM;2;COMMON;250 MM;RD/BK [P0738:05: {1.0}(X7)]
14 1.0000 PC A81-00000-04690 WIRE HARNESS;AWG:18;UL1015;3.96 MM;5;COMMON;60 MM;ALL
BLACK PIN1 RED
[P0738:05: {1.0}(X5)]
15 1.0000 PC A81-00000-04691 WIRE HARNESS;AWG:18;UL1015;3.96 MM;5;COMMON;120 MM;ALL
BLACK PIN1 RED
[P0738:02: {1.0}(X33)]
16 1.0000 PC A81-00000-04692 WIRE HARNESS;AWG:18;UL1015;3.96 MM;7;COMMON;190 MM;ALL
BLACK PIN1 RED
[P0738:02: {1.0}(X35)]
17 1.0000 PC A81-00030-32002 CABLE;LENGTH:150mm;POLES:3;AWG:18;UL1015;ONE SIDE 7mm
STRIP/TINNED;PIN2 NO CONNECTION
18 0.0000 PC A81-06070-52042 WIRE HARNESS;LENGTH:60mm;AWG:18;P:3mm96;UL1015;HOUSING
- BOARD IN CONNECTOR;POLES:5;PIN1 RED/OTHERS BLK;PIN 2 & 4
HAS NO CONNECTION
[P0738:05: {0.0}(X5)]
19 1.0000 PC A81-09030-26800 WIRE HARNESS;LENGTH:90mm;ZEE;AWG:26;P:2mm;PIN 2 IS
SHIELDED;HOUSING - BOARD IN CONNECTOR;POLES:2;PIN1
RD/OTHERS BK;SHIELDED_01
[P0738:02: {1.0}(X31)]
20 1.0000 PC A81-12030-26845 WIRE HARNESS;LENGTH:120mm;ZEE;AWG:26;POLES:2;HOUSING -
BOARD IN CONNECTOR;P:2mm;PIN 2 IS SHIELDED;PIN1
RED/OTHERS BLK;SHIELDED@
[P0738:02: {1.0}(X41)]
21 0.0000 PC A81-12070-52042 WIRE
HARNESS;LENGTH:120mm;AWG:18;P:3mm96;UL1015;HOUSING -
BOARD IN CONNECTOR;POLES:5;PIN1 RED/OTHERS BLK;PIN 2 & 4
HAS NO CONNECTION
[P0738:02: {0.0}(X33)]
22 0.0000 PC A81-12130-36042 WIRE HARNESS;LENGTH:120mm;AWG:26;P:2mm;HOUSING-BOARD
IN CONNECTOR;POLES:3;PIN2 NO CONNECTION;PIN1 RED/OTHERS
BLK
[P0738:05: {0.0}(X3)]
23 1.0000 PC A81-14030-26842 WIRE HARNESS;LENGTH:140mm;ZEE;AWG:26;POLES:2;PIN 2 IS
SHIELDED;HOUSING - BOARD IN CONNECTOR;P:2mm;PIN1
RD/OTHERS BK
[P0738:02: {1.0}(X42)]
24 1.0000 PC A81-15030-26840 WIRE HARNESS;LENGTH:150mm;ZEE;AWG:26;P:2mm;HOUSING-
BOARD IN CONNECTOR;POLES:2;PIN1 RED/OTHERS BLK;PIN 2 IS
SHIELDED
[P0738:02: {1.0}(X32)]
25 0.0000 PC A81-16030-26040 WIRE HARNESS;LENGTH:160mm;AWG:26;P:2mm;HOUSING-BOARD
IN CONNECTOR;POLES:2;PIN1 RED/OTHERS BLK;PIN 2 IS SHIELDED
26 2.0000 PC A81-16030-26840 WIRE HARNESS;LENGTH:160mm;ZEE;AWG:26;P:2mm;HOUSING-
BOARD IN CONNECTOR;POLES:2;PIN1 RED/OTHERS BLK;PIN 2 IS
SHIELDED
[P0738:05: {2.0}(X4,X10)] X8,X9
