Bühler technologies BWT Series - Technische Daten BWT B05, B08 und B15; Technical Data BWT B05, B08 and B15

Bedienungs- und Installationsanleitung
Installation- and Operation Instruction
Öl / Wasserkühler BWT / oil / water cooler BWT
16
BX340001, 10/2010 Art. Nr. 34001
8.4 Technische Daten
BWT B05, B08 und B15
8.4 Technical Data
BWT B05, B08 and B15
Abmessungen in mm (inch) Dimensions given in mm (inch)
20 (0.79) 20 (0.79)
20 (0.79)
FF F
72 (2.83) 72 (2.83)
(...x010)
(...x020 / ...x030)
76 (2.99)
72 (2.83)
40 (1.57)
BWT B05
BWT B08
BWT B15
F1
F1
F1
F2
F2
F2
F3 F3
F3
F4 F4
F4
40 (1.57) 40 (1.57)
189 (7.44) 154 (6.06)
278 (10.94)
432 (17.01) 466 (18.35)
312 ( 12.28) (...x010)
317 (12.48) (...x020 / ...x030)
Typ
Type
Artikel-
Nr.
Part No.
F
F
Kühlleistung
Cooling
performance
Ölanschluss
Oil ports*
wrench size
F3, F1
Wasser-
anschluss
Water ports*
wrench size
F2, F4
Gewicht
(Netto)
Net
Weight
Volumen
Liter
Volume
BWT B05x010 3405010
30 mm
1.18 in
1,5 - 5,0 kW
2.0 - 6.7 hp
G ¾ 36 mm G ½ 27 mm
1,0 kg
2.2 lb
0,1 l
0.03 gal
BWT B05x020 3405020
53 mm
2.09 in
1,5 - 11 kW
2.0 - 14.8 hp
G ¾ 36 mm G ½ 27 mm
1,5 kg
3.3 lb
0,2 l
0.05 gal
BWT B08x010 3408010
30 mm
1.18 in
2,5 - 6,0 kW
3.6 - 8.0 hp
G ¾ 36 mm G ½ 27 mm
1,6 kg
3.5 lb
0,5 kg
0.13 gal
BWT B08x020 34080200
53 mm
2.09 in
5,0 - 16 kW
6.7 - 21.5 hp
G ¾ 36 mm G ½ 27 mm
2,0 kg
4.4 lb
1,0 kg
0.26 gal
BWT B08x030 34080300
76 mm
2.99 in
10 - 25 kW
13.4 - 33.5 hp
G ¾ 36 mm G ½ 27 mm
3,0 kg
6.6 lb
1,5 kg
0.4 lb
BWT B15x030 3415030
76 mm
2.99 in
6,0 - 30 kW
8.0 - 40.2 hp
G ¾ 36 mm G ½ 27 mm
4,0 kg
8.8 lb
2,0 kg
0.53 lb
*Threads according to ISO 228
