10-18 Vehicle Care
2.4L L4 Engine without eAssist
1. Open the hood. See Hood on
page 10‑5.
A. Screws (6)
B. Air Duct Clamp
C. Electrical Connector
2. Disconnect the outlet duct by
loosening the air duct clamp (B).
3. Disconnect the electrical
connector (C).
4. Remove the screws (A) on top of
the engine air cleaner/filter
housing.
5. Lift the filter cover housing away
from the engine.
6. Pull out the filter.
7. Inspect or replace the engine
air cleaner/filter.
8. Reverse Steps 2 through 4 to
reinstall the filter cover housing.
2.4L L4 Engine with eAssist
1. Open the hood. See Hood on
page 10‑5.
2. Remove the five screws on top
of the engine air cleaner/filter
housing.
3. Lift the filter cover housing away
from the engine air cleaner/filter
housing.
4. Pull out the filter.
To Next Page
