Vehicle Care 10-13
2. Disconnect the cover fitting from
the ventilation tube (A).
3. Disconnect the wiring harness
connector from the sensor (B).
A. Clamp
B. Screws
C. Housing Cover
D. Filter
E. Base
4. Loosen the outlet duct
clamp (A).
5. Loosen the six housing
cover (C) screws (B).
6. Remove the housing cover (C)
with outlet duct.
7. Remove the filter (D) and any
loose debris that may be found
in the base (E).
8. Inspect or replace the filter (D).
9. Reverse Steps 2 through 6
to reinstall the housing cover
and reconnect the electrical
connector to the sensor.
10. Reinstall the engine cover.
See Engine Cover on
page 10‑7.
{
WARNING
Operating the engine with the air
cleaner/filter off can cause you
or others to be burned. The air
cleaner not only cleans the air;
it helps to stop flames if the
engine backfires. Use caution
when working on the engine
and do not drive with the air
cleaner/filter off.
Notice: If the air cleaner/filter is
off, dirt can easily get into the
engine, which could damage it.
Always have the air cleaner/filter
in place when you are driving.
