Seats and Restraints 3-13
Removing the Third Row Seats
To remove a third row seat:
1. Remove the cargo
management system,
if available and installed.
See Cargo Management
System on page 4‑4.
2. Remove anything on or under
the seat.
Notice: Folding a rear seat with
the safety belts still fastened may
cause damage to the seat or the
safety belts. Always unbuckle the
safety belts and return them to
their normal stowed position
before folding a rear seat.
3. Fold the seatback down.
See “Folding the Seatback”
earlier in this section.
4. Remove the rear bolts on the
floor on each side of the seat.
5. Remove the seat by tilting it
slightly upward, and then pulling
it out of the rear of the vehicle in
one motion.
6. Replace the bolts in the floor
holes for storage.
Installing the Third Row Seats
To reinstall a third row seat:
1. Before installing the seat
the seatback must be folded
forward. See “Folding the
Seatback” earlier in this section.
The seats must be placed in
the proper locations to attach
correctly. The wider seat must
be installed on the driver side
and the narrower seat on the
passenger side. Remove the
bolts from the holes in the floor
before installing the seats.
2. Place the seat on the vehicle
floor so that the front seat hooks
are on the vehicle bars.
3. Reinstall the bolts, and torque to
55 Y (41 lb ft). Pull up on the
seat to make sure it is locked
in place.
4. Raise the seatback to the
upright position. Push and pull
on the seatback to make sure it
is locked into place.
5. Reconnect the center safety belt
mini-latch to the mini-buckle.
Do not let it twist.
