10-76 Vehicle Care
6. Make sure the tire is stored
securely. Push, pull (A), and
then try to turn (B) the tire. If the
tire moves, use the wrench to
tighten the cable.
Storing the Flat Tire
1. Remove the cable package from
the jack storage area.
2. Remove the small center cap by
tapping the back of the cap with
the extension of the shaft, if the
vehicle has aluminum wheels.
3. Put the flat tire in the rear
storage area with the valve
stem pointing toward the
rear of the vehicle.
A. Cable
B. Liftgate Hinges
C. Spare Tire Heat Shield
D. Center of the Wheel
E. Door Striker
4. Pull the cable (A) through the
door striker (E), the center of the
wheel (D), and the plastic spare
tire heat shield (C), as shown.
5. Hook the cable onto the outside
portion of the liftgate hinges (B).
6. Hook the other end of the cable
onto the outside portion of the
liftgate hinge on the other side
of the vehicle.
