Vehicle Care 10-33
Bulb Replacement
For the proper type of replacement
bulbs, see Replacement Bulbs on
page 10‑37.
For any bulb‐changing procedure
not listed in this section, contact
your dealer.
Halogen Bulbs
{
WARNING
Halogen bulbs have pressurized
gas inside and can burst if you
drop or scratch the bulb. You or
others could be injured. Be sure
to read and follow the instructions
on the bulb package.
Headlamps, Front Turn
Signal and Parking
Lamps
Base Headlamp Assembly
(Passenger Side Shown, Driver
Side Similar)
A. High‐Beam Headlamp
B. Turn Signal Lamp
C. Low‐Beam Headlamp/Daytime
Running Lamp (DRL)
D. Parking Lamp
E. Sidemarker Lamp
Up–Level Headlamp Assembly
(Passenger Side Shown, Driver
Side Similar)
A. High/Low‐Beam Headlamp ‐ To
be replaced at the dealer only
B. Turn Signal Lamp
