Vehicle Care 10-41
Fuse
Number
Usage
42 Radiator Fan 1
43 Not Used
44
Headlamp Washer
System (if equipped)
45 Radiator Fan 2
46
Terminal 87, Main
Relay
47 Oxygen Sensor
48 Fog Lamps
49
Right Hand Low
Beam, High Intensity
Discharge
Headlamp
50
Left Hand Low
Beam, High Intensity
Discharge
Headlamp
51 Horn
52
Motor
Indicator Lamp
Fuse
Number
Usage
53
Ignition, Inside
Rearview Mirror
54 Not Used
55 Power Windows
56 Windshield Washer
57 Not Used
58 Not Used
59
Secondary Air
Induction
60 Heated Mirrors
61 Not Used
62
Canister Vent
Solenoid
63 Not Used
64 Not Used
65 Not Used
66 Not Used
67
Fuel System Control
Module
Fuse
Number
Usage
68 Not Used
69 Battery Sensor
70 Not Used
71 Not Used
Relay
Number
Usage
K1 Not Used
K2 Starter
K3 Cooling Fan (LHU)
K4 Front Wiper (Step 2)
K5
Front Wiper (Step 1,
Interval)
K6 SAI Valve
K7 Main Relay
K8 Not Used
K9
Cooling Fan
(LAF/LHU)
K10 Cooling Fan (LAF)
