Picture No. 37 continued
Measuring example:
Thickness of intermediate washer during the measuring procedure: 0.60 mm
Measured axial clearance of shaft: 0.08 mm
Correct tightening 0.03 – 0.08 mm (average value): 0.055 mm
Thickness of compressed liquid jointing: 0.02 mm
Theoretical thickness of intermediate washer: 0.755 mm
In practice the intermediate washer will be 0.73 – 0.78 mm.
Then insert the correct intermediate washers in the bores (max. 2 washers in each bore)
and fit the bearing outer collars after heating with Loctite No. 601.
Pre-Mounting of Shifting Fork.
Place the reversing shaft in the shifting fork and secure it with the threaded pin and smear it
with Loctite No. 241.
“NOTE”: the long side of the reversing shaft points to the left when the position of the
shifting fork is as shown on the drawing.
