OPERATING INSTRUCTIONS
Operating Instructions
ouTlook TroubleshooTInG
CONDITION POSSIBLE SOURCES ACTION
Outlook will not turn on Installation/ Connection
Make sure that the fuse jack is securely fastened to the
fuse socket.
Check that the fuse is working properly where the OutLook
fuse is plugged into.
Make sure that the OBDII Harness is properly plugged into
the OBDII port.
Will only display Boost &
Pyro
Improper Truck Selection
Check and ensure the proper truck is selected.
The 7.3 L Ford will only display this information.
Make sure you have proper connections everywhere.
Also, make sure that there are no bent pins in any of the
connectors.
Will only display pyrometer Improper Truck Selection
Check and ensure the proper truck is selected.
Make sure you have proper connections everywhere.
Also, make sure that there are no bent pins in any of the
connectors.
Will not adjust horsepower Improper Truck Selection Check and ensure the proper truck is selected.
Back light quit working Loose connection
Contact Technical Support if the OutLook is otherwise
functioning normal.
OutLook will not display
proper temperature EGTs
Pyrometer Probe
Connections Incorrect
Check the orientation of the Pyrometer Probes, long wire
to short and short to long, on the Pyro 1 and Pyro 2 wires
for the OutLook Main Harness.
Make sure that the Pyrometer Probe for the Pre-turbo
probe is connected to the Pyro 1 wires on the OutLook
Main Harness.
Horse power & Torque
readings are low
Proper Use
The outlook records horsepower and torque from 1/4 mile
times. The vehicle will have to go all the way through
the 1/4 mile as fast as possible to get accurate ywheel
horsepower numbers.
For more information on up-to-date troubleshooting guide for
the OutLook , go to
www.bullydog.com/Product_Updates.php
