Bunn IMIX-3 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
19
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
23 37297.0000 1 Elbow, .25" Flare x .75" FTHRD
24 06866.0002 1 Tee, .50" Barb
25 20976.0017* 1 Tube, Silicone .375" ID x 2.0" (Order item 32)
26 20976.0055* 1 Tube, Silicone .375" ID x 9.0" (Order item 32)
27 36233.0000 1 Valve, Water Inlet 120V
36233.0001 1 Valve, Water Inlet 230V
32283.0000 2 Screw, Pan Head M4 x 6MM
28 01592.0001 1 Bushing, Snap 1.18" Dia. Hole
29 37099.0000 1 Bracket, Tank Mounting Lower
00970.0000 4 Nut, Keps #8-32
30 36222.0001* 1 Insulation, Tank
31 28526.1000 - Tube, Silicone .312" ID x .562" OD x 12"
28526.1001 - Tube, Silicone .312" ID x .562" OD x 36"
28526.1002 - Tube, Silicone .312" ID x .562" OD x 60"
28526.1003 - Tube, Silicone .312" ID x .562" OD x 120"
32 20976.1000 - Tube, Silicone, .375" ID x .50" OD x 12.0"
20976.1001 - Tube, Silicone, .375" ID x .50" OD x 36.0"
20976.1002 - Tube, Silicone, .375" ID x .50" OD x 120.0"
TANK, HEATER AND OVERFLOW PROTECTION
Not Illustrated
37509 090707
