Bunn IMIX-3 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
21
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
1 26369.1000 1 Plug (Includes item 2)
2 24733.0011 4 O-Ring
3 39285.1001 3 Valve, Liquid Dispense 120V (Includes item 2)
39285.1002 3 Valve, Liquid Dispense 230V (Includes item 2)
01326.0000 3 Screw, Truss Head #10-32 x .25"
4 28526.0027* 3 Tube, Silicone .312" ID x 16.5" (Order item 9)
5 21801.0002 3 Tube, .375" OD x 1.50"
6 12422.0001 3 Clamp, Hose .59"/.66" ID
7 25803.0000 3 Water Inlet, Mixing Chamber
8 37970.0000 4 Grommet
9 28526.1001 - Tube, Silicone .312" I.D. x .438" O.D. x 36"
28526.1002 - Tube, Silicone .312" I.D. x .438" O.D. x 60"
28526.1003 - Tube, Silicone .312" I.D. x .438" O.D. x 120"
DISPENSE VALVES AND LINES
Not
Illustrated
37509 090707
