Page 3
INTRODUCTION
This equipment will brew coffee or tea into an awaiting Server. The brewer may have an auxiliary hot water fau-
cet. It is only for indoor use on a sturdy and level counter or shelf. Please install in an area where there are no
water jet devices.
The Infusion Series, similar to the DBC BrewWISE, incorporates a wireless interface system that allows the MHG
or DBC Grinders to load certain information into the "programming chip" located inside the handle of the funnel.
This information includes what flavor of coffee is being ground and what batch size will be brewed (half or full).
Once the correct flavor name and amount of coffee is ground, the funnel is loaded into the brewer. The information
from the funnel handle is then transferred into the brewer. The brewer then takes this information and dispenses
the amount of water preset in the brewer for that particular flavor of coffee and batch size. The brewer can also
be programmed to adjust different functions of the brewing process, such as brew temperature, brew volumes,
bypass percentages, pulse brew, dilution, etc. This allows the operator to program a certain "recipe" for each
coffee or tea flavor to be brewed.
The Infusion Series Coffee and Tea Brewer is able to brew coffee/tea with recipe settings and has
the following features: By-Pass(ITCB HV only), Dilution, Dilution Delay, Pre-Infusion, SmartWAVE and Pulse
Brew, BrewWISE, and LCD for digital readout and programming along with the Smart Funnel and Server De-
tect options for coffee. Other features are Energy Savings mode, BUNNlink compatible, Smart Reader compat-
ible, Freshness Timer and USB port for operators to save and load recipes or new software onto brewer.
CONTENTS
Warranty .............................................................................................................2
Introduction ........................................................................................................3
CE/North American Requirements ......................................................................4
Operator Notices .................................................................................................4
Electrical Requirements ......................................................................................5
Plumbing Requirements .....................................................................................6
Tank Drain ...........................................................................................................6
Initial Set-Up .......................................................................................................7
Brewing Coffee ....................................................................................................7
Brewing Tea ........................................................................................................8
Cleaning ..............................................................................................................9
Operating Controls ............................................................................................10
Programming/Service Access ...........................................................................11
Programming/Service Menu .............................................................................11
Viewing Asset, Serial and Service Number .......................................................13
Calibration .........................................................................................................10
Programming/Service Access ...........................................................................11
Programming/Service Menu .............................................................................11
Sprayhead/Bypass/Dilution Calibration .............................................................13
Viewing Asset, Serial and Service Number .......................................................14
Edit Recipes ......................................................................................................15
Machine Settings ..............................................................................................17
ITCB-DV ................................................................................................................. Dual Voltage Machine
ITCB HV ............................................................................................................................... High Volume
