ITEM PART NO. QTY. DESCRIPTION
19
* Indicates the part number listed is OBSOLETE. ^ Indicates the part number listed is for reference only.
ELECTRICAL & OPERATING CONTROLS
1 36367.0000 1 Membrane Switch
2 32572.1000 1 Sensing Coil
3 35956.0000 1 Fastener
4 36366.0000 1 Mount, Board (2 Used on Early Models)
5 36373.1000 1 Control Board
00973.0000 2 Nut, Keps #6-32
6 01533.0011 2 Spacer
7 36449.1000 1 Memory Circuit Board
00970.0000 2 Nut, Keps #8-32
8 01533.0002 2 Spacer
9 34307.1001 1 Transformer (Models ITCB-DV & ITCB-C-DV)
34307.1003 1 Transformer (Models ITCBB, 200V)
34307.1002 1 Transformer (Models ITCBA, 230V)
00970.0000 2 Nut, Keps #8-32
10 36587.0000 1 Plug, Bezel
11 36368.0000 1 Decal, Top
12 07038.0000 1 Terminal Block (Models ITCB-DV & ITCB-C-DV)
01106.0001 1 Terminal Block (Models ITCBB, 200V)
01106.0003 1 Terminal Block (Models ITCBA, 230V)
01317.0000 2 Screw, Truss Head #8-32 x .50"
13 01327.0000 1 Screw, Grounding #10-32 x .38" (Early models)
37804.0000 1 Screw, Grounding #8-32 x .50" (Late models)
14 23522.0001 1 Switch, Toggle (Dual Voltage Brewers only)
15 36420.1000 1 Bracket w/Decals (Incls items 13 & 16-20) (Models ITCB-DV & ITCB-C-DV)
37482.1001 1 Bracket w/Decals (Incls items 13 & 17-20) (Models ITCBA, 230V & ITCBB, 200V)
02308.0000 2 Screw, Pan Head #8-32 x .38"
16 34056.0001 1 Decal, Voltage Selection (ICB-DV models only)
17 00985.0000 1 Decal, Individual Circuit Info
18 00870.0000* 1 Decal, Use Copper Wire Only
19 12394.0002* 1 Decal, Supply Connection
20 00824.0000 2 Decal, Ground
21 01685.0000 1 Connector, Cable
22 36398.0000 1 Hole Plug
23 29446.0003 1 EMI Filter (Models ITCBA, 230V)
01347.0000 4 Screw, Truss Head #6-32 x .38"
24 27705.0000 1 Terminal Lug (Models ITCBA, 230V & ITCBB, 200V)
02308.0000 1 Screw, Pan Head #8-32 x .38"
(Continued)
(Early models Only)
36747 061507
To Next Page
