Bunn OT - Page 123

Page 31
BLK
BLK
BLK
BLU
LIMIT
THERMOSTAT
L1
BLK
BREW STATION WARMER
BLU
BLU/BLK
BLK
BLK
P1
P3
P2
GRN/YEL
SCHEMATIC WIRING DIAGRAM OT35B
BLK
L2
BLK
BLK
P1, P2, & P3 ARE
PINS OF A
POLARIZED
THREE-PIN
CONNECTOR.
200 VOLTS AC
2 WIRE
SINGLE PHASE
50-60 HZ
RED
TANK HEATER
BLK
UPPER WARMER
BLK
P3
P2
RED
RED
RED
RED
RED
BLK
RED
BLU
READY INDICATOR
BLK
SW. & THERMOSTAT
10637.0000B 7/00 © 1991 Bunn-O-Matic Corporation
WHI/GRNWHI/BLU
WHI
BREW
TIMER
SOL
T5
T1
T2
T4
T3
32440 070700
Part II
