Bunn OT - WARMER ASSEMBLIES (Models RL & RT)

ITEM PART NO. QTY. DESCRIPTION
27
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
WARMER ASSEMBLIES (Models RL & RT)
1 03697.0000 5 Warmer Assy, 100W/120V (Includes items 2 thru 6)
02817.0000 5 Warmer Assy, 240V (Includes items 2 thru 6)
01303.0000 16 Screw, PNH PHH #4-40 x .50"
01304.0000 1 Screw, PNH PHH #4-40 x .75"
00916.0000 17 Fastener, "J" Type #4-40
2 03656.0000 1 Dish
3 13042.0001 1 Spacer (120V only)
4 01143.0000 1 Element (100W/120V)
01951.0000 1 Element (100W/240V)
5 05212.0000 1 Plate
6 00970.0000 2 Nut
7 03311.0000 1 Warmer Assy, High Heat 120V (Includes items 8 thru 11)
- - - - - - - - 1 Warmer Assy, High Heat 240V (Includes items 8 thru 11)
01303.0000 3 Screw, PNH PHH #4-40 x .50"
00916.0000 3 Fastener, "J" Type #4-40
8 01161.0000 1 Element, 120V (Includes hardware below)
01907.0000 1 Element, 240V (Includes hardware below)
01503.0000 3 Washer
00910.0000 3 Nut, Hex #10-32
9 01198.0000 1 Plate, Retainer
01332.0000 1 Screw, PNH SLTD #10 x .50"
10 01197.0000 1 Dish
11 00909.0000 3 Nut, Brass #10-32
Models with High
Heat Warmers
10785 022405
