ITEM PART NO. QTY. DESCRIPTION
15
TANK HEATER & SAFETY DEVICES
1 29329.1000 1 Thermostat, Limit
2 02536.0000 1 Grommet, Probe
3 20936.1000 1 Probe Kit (Includes items 4 thru 6)
4 01501.0000 1 Washer
5 20203.0100 1 Lockwasher, Internal Tooth #8
6 00908.0000 1 Nut, Hex #8-32
7 12524.1000 1 Tank Heater, 1800W @ 120V
20922.1000 1 Tank Heater, 3300W @ 240V
20922.1003 1 Tank Heater, 3700W @ 208V Each includes item 8
12322.1000 1 Tank Heater, 4000W @ 240V
12305.1000 1 Tank Heater, 3700W @ 200V
00908.0000 4 Nut, Hex #8-32
8 12398.0002 1 Gasket, Tank Heater
9 20229.1000 1 Tube Assy, Vent
10 02536.0000 2 Grommet .375" I.D.
11 20930.0000 1 Bracket, Overflow Cup Mounting
12 03803.0000 1 Switch Assy, Liquid Level (Includes items 13, 14 & 15)
00946.0000 1 Nut, Hex .125" FPT
13 03633.0000 2 Gasket, Float Switch (Only 1 used in this application)
14 - - - - - - - - 3 Washer, Adjusting (DO NOT USE IN THIS APPLICATION)
15 03807.0000 1 Clip, Spring
16 12552.0000 1 Overflow Cup Assy
00965.0000 2 Nut, Zip #8-32
17 12422.0000 1 Clamp, Hose .47"/.54" I.D.
18 - - - - - - - - 1 Tube, Silicone .312" I.D. x 21.50" (Order item 23)
19 12527.0001 1 Triac/Heat Sink Assy (Includes items 20, 21 & 22)
00971.0000 1 Nut, Keps #10-32
20 12561.0000 1 Heat Sink, Copper
21 12565.0002 1 Triac Assy, 40 AMP
02328.0003 1 Screw, Pan Head #6-32 x .312"
01520.0000 1 Lockwasher, Split #6
22 M2522.1000 - Heat Sink Compound
23 03236.1001 - Tube, Silicone .312" I.D. x 36.0"
Not Illustrated
10772 090800
