ITEM PART NO. QTY. DESCRIPTION
23
1 20945.0001 1 Valve Assy, Needle By-Pass
2- - - - - - - - 1 Tube, Silicone .25" I.D. x 2.60" (Order item 14)
3 23849.0000 1 By-Pass Valve Assy, 120V
23849.0001 1 By-Pass Valve Assy, 200V
23849.0002 1 By-Pass Valve Assy, 240V
4 24298.0000 1 Coil Assy, By-Pass Valve 120V
24298.0001 1 Coil Assy, By-Pass Valve 240V
24298.0002 1 Coil Assy, By-Pass Valve 200V
5 23254.0000 4 Screw #8-32
6 23256.0000 1 Spacer Plate
7- - - - - - - - 1 Spring (Not available separately order item 16)
8- - - - - - - - 1 Plunger (Not available separately order item 16)
9 23255.0000 1 Diaphragm
10 - - - - - - - - 1 Body (Not available separately order item 3)
11 - - - - - - - - 1 Elbow (Models with First Type By-Pass. Order item 17 & Upper Component
Bracket on page 13)
20201.1601 1 Elbow, 90° .375" Barb x .25" MPT (Models with Second Type By-Pass)
12 - - - - - - - - 1 Tube, Silicone (Models with First Type By-Pass. Order item 17 & Upper Component
Bracket on page 13))
- - - - - - - - 1 Tube, Silicone .375" I.D. x .62" O.D. x 8.50" (Models with Second Type
By-Pass.(Order item 15)
13 12422.0000 2 Clamp, Hose .47"/.54" I.D. (Use with .25" I.D. tube)
12422.0001 2 Clamp, Hose .59"/.66" I.D. (Use with .375" I.D. tube)
14 11707.1000 1 Tube, Silicone .25" I.D. x 12.0"
11707.1001 1 Tube, Silicone .25" I.D. x 36.0"
11707.1002 1 Tube, Silicone .25" I.D. x 120.0"
15 20976.1000 1 Tube, Silicone .375" I.D. x 12.0"
20976.1001 1 Tube, Silicone .375" I.D. x 36.0"
20976.1002 1 Tube, Silicone .375" I.D. x 120.0"
16 11517.0008 - Valve Repair Kit (Includes one each of items 7, 8 & 9)
17 26109.0000 - Kit, Variable By-pass (Converts First Type Electro/Mechanical
By-pass to Second Type)
Includes items 4 thru 10
WATER BY-PASS
Not Illustrated
10772 090800
