Bunn SINGLE - Page 25

ITEM PART NO. QTY. DESCRIPTION
25
1 20933.0000 1 Dispensing Valve Assy, 120V
20933.0001 1 Dispensing Valve Assy, 200V
20933.0002 1 Dispensing Valve Assy, 240V
2 22305.0000 1 Coil Assy, Dispensing Valve 120V
22305.0002 1 Coil Assy, Dispensing Valve 240V
22305.0003 1 Coil Assy, Dispensing Valve 200V
3 23254.0000 4 Screw #8-32
4 23256.0000 1 Spacer Plate
5- - - - - - - - 1 Spring (Not available separately order item 19)
6- - - - - - - - 1 Plunger (Not available separately order item 19)
7 23255.0000 1 Diaphragm
8- - - - - - - - 1 Body (Not available separately order item 1)
9 12422.0001 2 Clamp, Hose .59" x .66" I.D. (2 additional used on models with Second Type
Electro/Mechanical by-pass)
10 - - - - - - - - 1 Tube, Silicone .38" I.D. x .62" O.D. x 9.50" (Order item 18)
11 20926.0000 1 Fitting Assy, Sprayhead (Mechanical Type By-Pass) (Shown)
- - - - - - - - 1 Fitting Assy, Sprayhead (Models with First Type Electro/Mechanical By-pass.
Order item 20 & Upper Component Bracket on page 13)
12 01075.0000 1 Nut, Hex .438" - 20
13 01082.0002 1 Sprayhead
14 - - - - - - - - 1 Tube, Silicone .38" I.D. x .62" O.D. x 6.50" (Order item 18)
15 06866.0000 1 Fitting, Tee .375" Barb
16 - - - - - - - - 1 Tube, Silicone .38" I.D. x .62" O.D. x 2.25" (Order item 18)
17 25647.0000 1 Tube, Sprayhead
18 20976.1000 1 Tube, Silicone .38" I.D. x .62" O.D. x 12.0"
20976.1001 1 Tube, Silicone .38" I.D. x .62" O.D. x 36.0"
20976.1002 1 Tube, Silicone .38" I.D. x .62" O.D. x 120.0"
19 11517.0008 - Valve Repair Kit (Includes one each of items 5, 6 & 7)
20 26109.0000 - Kit, Variable By-pass (Converts First Type Electro/Mechanical
By-pass to Second Type)
Includes items 2 thru 8
DISPENSE VALVE AND SPRAYHEAD
Models with Second
Type Electro/Mechanical
By-pass
Not illustrated
10772 090800
