Bunn SINGLE - Page 29

ITEM PART NO. QTY. DESCRIPTION
29
1- - - - - - - - 1 Dustcap W/Chain (First Type. Not available, order second type Dustcap)
27657.0000 1 Dustcap, Socket (Second Type)
01382.0000 1 Screw, Truss Head #6-32 x .375"
00973.0000 1 Nut, Keps #6-32
2 12274.0002 1 Socket Assy W/Leads, Interface
3 06335.0000 1 Contactor Assy, 120V Coil
06335.0002 1 Contactor Assy, 240V Coil
01327.0000 2 Screw, Pan Head #10-32 x .375"
4 12517.0002 1 Ready Light Replacement Kit (Includes item 5)
25292.0000 1 Lockwasher M6
34130.0000 1 Nut M6
5 03851.0000 2 Wire Nut, 2 - 22AWG
6 12984.0002 1 Light Assy, 120V (Includes item 7)
12984.0004 1 Light Assy, 240V (Includes item 7)
7 04243.0000 2 Terminal Housing, Receptacle
8 12246.0000 1 Knob, Rotary Switch
9 02753.0000 1 Switch, On/Off 120V
02754.0000 1 Switch, On/Off 240V
10 02628.0000 1 Switch, Momentary- Start
11 20969.0000 1 Switch Assy, Rotary (Mechanical Valve By-Pass)
20969.0001 1 Switch Assy, Rotary (Electro/Mechanical Valve By-Pass)
12 01309.0000 1 Ground Screw W/Terminal Washer #10-32 x .50"
13 23004.0000 1 Bracket, Terminal Block Mounting
02308.0000 2 Screw, Pan Head #8-32 x .375"
14 07038.0000 1 Terminal Block, 3 Pole (120/240V) (Shown)
01106.0000 1 Terminal Block, 2 Pole (120V)
01106.0001 1 Terminal Block, 2 Pole (200/240V)
01317.0000 2 Screw, Truss Head #8-32 x .375"
15 03628.0000 1 Receptacle, Grounded (Not used on 200V or 230V Brewers)
16 01590.0000 1 Connector, Cable
17 23354.0000 1 Wiring Harness, Main (120/240V Mech. Thermostat)
23354.0001 1 Wiring Harness, Main (120V Mech. Thermostat)
23354.0002 1 Wiring Harness, Main (120/240V Electronic Control)
23354.0003 1 Wiring Harness, Main (120V Electronic Control)
23354.0004 1 Wiring Harness, Main (200/240V Mech. Thermostat)
23354.0005 1 Wiring Harness, Main (200/240V Electronic Control)
18 23378.0000 1 Wiring Harness, Contactor (200/240V)
23378.0001 1 Wiring Harness, Contactor (120V)
Brewers with Mechanical Thermostat only
ELECTRICAL CONTROLS & READY LIGHT
Brewers with Electronic
Control only
Not Illustrated
10772 031303
