Bunn SINGLE - Operating Controls; Brew Selector Switch; On;Off Switch; Start Switch

ITEM PART NO. QTY. DESCRIPTION
7
1 20948.0001 1 Bracket, Component Mounting
02308.0000 4 Screw, Pan Head #8-32 x .375"
2 01533.0000 2 Spacer, Nylon .375"
3 02620.1040 1 Timer, 8 Min. 120V (Shown)
02620.1041 1 Timer, 8 Min. 240V
32400.0002 1 Timer, Digital 120V
32400.0003 1 Timer, Digital 240V
01347.0000 2 Screw, Truss Head #6-32 x .375" (Not used with Digital Timer)
01510.0000 2 Lockwasher, External Tooth #6
01388.0000 2 Screw, Truss Head #6-32 x .75"
4 04314.0001 1 Thermostat Kit (Includes item 5, 7 & 8)(Late Models)(Also replaces
early model thermostat)
02308.0000 1 Screw, Pan Head #8-32 x .375" (Mounting)
20762.0000 2 Screw, Binding Head #8-32 x .25" (Terminal Screws)
5 07073.0000 1 Grommet, Thermostat
6 07074.1026 1 Control Board, Level (120V)
07074.1027 1 Control Board, Level (240V)
02308.0000 2 Screw, Pan Head #8-32 x .375"
01511.0000 2 Lockwasher, External Tooth #8
7 00720.0000 1 Knob, Thermostat
8 28377.0000 1 Noise Suppressor (Not used with Digital Timer)
SINGLE SET TIMER & MECHANICAL THERMOSTAT
First Type
Second Type
10772 110501
