25. Push down until the
Hopper Lock Plunger
snaps into place.
18. Place all parts in a clean sink with mild hot water (120°F) and sanitizer solution. Allow parts to soak for at least 5 minutes. Carefully
wash all components with a clean wash cloth in the hot water and sanitizer solution. Use a clean, soft bristle brush as needed for the
smaller components and tight areas. Do not immerse hopper lids. Use a commercial sanitizer that has 100 ppm of available chlorine with
a concentration level of at least 3% available chlorine (KAY-5 Sanitizer). Follow the sanitizer’s mixing instructions to ensure 100 ppm of
available chlorine.
19. Wash the Drum, Hopper Drip Trays, Top Covers, and outer enclosure using a clean wash cloth that has been dampened in the hot water
and sanitizer solution. Pat particular attention to the shaft area and make sure it is thoroughly cleaned and sanitized.
20. Thoroughly rinse all surfaces with a clean wash cloth that has been dampened with hot water. Wipe dry with a clean dry wash cloth
before reassembling the dispenser.
NOTE: Although most parts are dishwasher safe, they may be affected by the chemicals in some commercial sanitizing agents. Do not place
the Hopper or Hopper Lids in a dishwasher. Rinse thoroughly before reassembly.
21. Replace the Auger
Nose Bushing inside the
front of the Hopper.
22. Install the Hopper
Seal over the flange at the
rear of the Cooling Drum
as shown. Install Auger
Shaft Seal (if used on this
machine).
23. Align the Auger Shafts
with the Augers. Push the
Augers as far as they will
go and rotate them so
the flat face of the Auger
Shaft is aligned with the
flat face of the Auger
nose.
24. Install the Hopper
over the Auger and Cool-
ing Drum and slide it into
place.
17. Remove the Drip Tray
and Cover.
16. Do not scratch this
surface when cleaning.
Deep scratches could
cause leakage around
the seal.
35113 111408

Other manuals for Bunn ULTRA-2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bunn ULTRA-2 and is the answer not in the manual?

Bunn ULTRA-2 Specifications

General IconGeneral
ModelULTRA-2
TypeFrozen Beverage Dispenser
Number of Hoppers2
RefrigerantR404A
Electrical120V, 60Hz
FeaturesTouchpad display
Dimensions32" H x 16" W x 24.5" D
