TROUBLESHOOTING (cont.)
Temperature Sensor Error
TEMPERATURE SENSOR SHORTED
TEMPERATURE SENSOR OPEN
Left side
Right side
Check wiring harness between
thermistor and control board
Left side
Right side
Product not covering
back end of drum.
Drum temperature
falls below 9° F.
Replenish product
Thermistor unplugged
or break in wiring
Check thermistor
circuit
