12
its cover.
5.2. Available versions
Device Supply voltage Order code
Timer 1078-1
12-24 V DC 060647
24-48 V AC, 50-60 Hz,
24-48 V DC
060621
110-230 V AC,
50-60 Hz
060620
Timer 1078-2
12-24 V DC 060648
24-48 V AC, 50-60 Hz,
24-48 V DC
060629
Configuration module 1077-2 for timer
1078-2
060638
English
13
5.3. Description of the name plates
1078-1
Supply: 110-230V/50-60Hz 0,5A
Output: 110-230V/50-60Hz 0,5A
S/N 1000
00060620 W43ML
Made in France
1
2
3
6 5 47
1. Type of the device
2. Power supply data
3. Data of the power supplied to the solenoid valve
4. Construction code
5. Conformity logo
6. Order code
7. Serial number
Fig. 1: Nameplate of the 1078
1077-000-00-002-000-000
00060638 W45LP
Made in France
1 2
4 3
English
13
14
1. Type of the device
2. Conformity logo
3. Construction code
4. Order code
Fig. 2: Nameplate of the 1077
English
15
6. TECHNICAL DATA
6.1. Conditions of use
Ambient temperature
1078
1077
(in operation)
-10°C...60°C
0°C...60°C
Air humidity < 85%, non condensated
Height above sea level max. 2000 m
Degree of pollution 2
Protection rating IP65, when screwed to the
solenoid valve at a torque rating
between 0,5 and 0,8 Nm, wired
and cable gland tightened
6.2. General technical data
6.2.1. Mechanical data
Part Material
Housing
1078
1077-2
PA6 or polyarylamide
Polyamide
Cover PSU
English
15
