With wheels mounted, both refl ectors must face outward. Failure to follow
this instruction can reduce trailer visibility at night and cause accident and
serious injury.
IV. Install Rear Refl ectors
In the hardware bag, you’ll fi nd the parts needed to install the rear refl ec-
tors:
(2) Refl ector bracket
(2) Self-tapping Phillips screw, bracket
(2) Rear refl ector, red
(2) Self-tapping slotted screw, refl ector
The refl ector brackets mount on the outside of
each side rail below the two snap studs, 4 7/8"
up from the bottom of the side-panel assembly.
The holes for the mounting screws are covered
by the blue fabric. First, insert the screw into
the refl ector bracket and drive the Phillips-head
self-tapping screws through the fabric into the
holes provided to mount the bracket. (Don’t
worry; this won’t harm the fabric.) Then mount
the red refl ectors onto the brackets with the
slotted-head, self-tapping refl ector mounting
screws. The bracket should be mounted as
shown in the illustrations.
Incorrect
Correct
Right Rear
Snap
Studs
To Next Page
