27| 46
218 POWER AMPLIFIER
FIGURE 1
STEREO MODE WIRING DIAGRAM
RIGHT CHANNEL LEFT CHANNEL
+
-
+
-
- -
+ +
MAINS
OFFON
G
G
Do not switch your hi-fi system on again until you are sure that all the devices
are connected correctly. Set your preamplifier to a low volume first.
