948 POWER CONDITIONER
FRONT PANEL
REAR PANEL 230 V EUVERSION SHOWN
11 AC outlet MAINS OUT 1
12 AC outlet MAINS OUT 1
13 AC mains switch
14 AC input terminal
15 AC outlet MAINS OUT 2
16 AC outlet MAINS OUT 2
17 AC outlet MAINS OUT 3
18 AC outlet MAINS OUT 3
19 Remote input terminal for turning on the power conditioner remotely
20 Earth connection for additional equipotential bonding
21 AC outlet MAINS OUT 4
22 AC outlet MAINS OUT 4
