OPERATING THE AMPLIFIER
The AC mains switch (7) is located at the rear of the housing. It disconnects the 956 MK2 from the AC
supply. When it is set to OFF the unit is completely disconnected, the LEDs on the front panel remain dark.
Switching to ON activates the stand-by mode and the left STAND BY-LED (1) on the front panel illuminates.
The POWER- button (2) on the front panel switches the 956 MK2 into operating mode or back into
stand-by mode. In operating mode STAND BY- LED (1) and POWER LED (3) are illuminated. In
stand-by mode only STAND BY- LED (1) lights up. After switching to operating mode the monitoring
system of the 956 MK2 takes a few seconds to check all circuits before enabeling the speaker outputs.
HOOK-UP OPTIONS
To use the 956 MK2 in STEREO mode make the following connections:
(4) input right channel
(6) speaker terminal right channel positive
(5) speaker terminal right channel negative
(12) input left channel
(10) speaker terminal left channel positive
(11) speaker terminal left channel negative
To use the 956 MK2 in MONO moder make the following connections:
(4) MONO-ADAPTER (14), red marking
(6) speaker terminal positive
(5) must not be connected
(12) MONO-ADAPTER (14), blue marking
(10) speaker terminal negative
(11) must not be connected
To use the 956 MK2 in BI-AMPING mode make the following connections:
(4) BI-AMP-ADAPTER (15), red marking
(6) speaker terminal positive for mid- to high-range drivers
(5) speaker terminal negative for mid- to high-range drivers
(12) BI-AMP-ADAPTER (15), blue marking
(10) speaker terminal positive for bass driver
(11) speaker terminal negative for bass driver
AC mains switch
POWER- button
STEREO operation
MONO operation
BI-AMPING
6
