BURNHARD WAYNE - Page 39

39
Ref. Description Quantity
1 Lid thermometer 1
2 Lid 1
3 Lid hinge screw 2
4 Lid handle 1
5 Enamelled cast iron grate 2
6 Stainless steel burner (left) 1
7 Stainless steel burner (right) 1
8 Piezo ignition 2
9 Firebox (body) 1
10 Left angle bracket (body) 2
11 Right angle bracket (body) 2
12 Thermal insulation A 4
13 Thermal insulation B 4
14 Baffle (front) 1
15 Main gas valve 2
16 Main gas distributor 1
17 Gas hose 1
18 Control panel screen 1
19 Control knob (regulator) 2
20 Grease trap 1
21 Grease trap holder 1
22 Handle 2
23 Stand (front) 1
24 Stand (rear) 1
25 Warning message flap 1
26 Shaft and spring 1
27 Cross channel 1
